GPS - C35-48-B
Specifications
- Type: Outrunner
- Weight: 161.00g (5.68oz)
- Diameter: 35.00mm (1.38in)
- Length: 48.30mm (1.90in)
- Shaft Diameter: 4.00mm (0.16in)
- Maximum Amps: 35
Constants
- kV: 950
- Rm: 0.082
- Io: 2.39
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10.025 | 2.39 | 9330 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 10x6 | 1 | 6.9 | 9 | 62 | 5910 | 33.6 | 491 | 17.32 | 90% |
| GWS HD 10x6 | 1 | 7.9 | 11.19 | 88 | 6660 | 37.8 | 622 | 21.94 | 89% |
| GWS HD 10x6 | 1 | 8.9 | 13.2 | 117 | 7380 | 41.9 | 764 | 26.95 | 87% |
| GWS HD 10x6 | 1 | 9.8 | 15.6 | 152 | 8040 | 45.7 | 919 | 32.42 | 86% |
| GWS HD 10x6 | 1 | 10.8 | 18 | 194 | 8670 | 49.3 | 1069 | 37.71 | 85% |
| GWS HD 11x7 | 1 | 6.9 | 13.1 | 90 | 5580 | 37.0 | 696 | 24.55 | 85% |
| GWS HD 11x7 | 1 | 7.8 | 16 | 124 | 6210 | 41.2 | 880 | 31.04 | 84% |
| GWS HD 11x7 | 1 | 8.8 | 19 | 167 | 6810 | 45.1 | 1061 | 37.43 | 81% |
| GWS HD 11x7 | 1 | 9.8 | 22.1 | 216 | 7380 | 48.9 | 1246 | 43.95 | 79% |
| GWS HD 11x7 | 1 | 10.6 | 24.4 | 258 | 7680 | 50.9 | 1380 | 48.68 | 76% |
| GWS HD 11x7 | 1 | 11.1 | 27.2 | 301 | 8190 | 54.3 | 1595 | 56.26 | 78% |
| APC E 11x7 | 1 | 7.6 | 16.4 | 124 | 5970 | 39.6 | 751 | 26.49 | 83% |
| APC E 11x7 | 1 | 11.1 | 28 | 310 | 7980 | 52.9 | 1380 | 48.68 | 76% |
| MAS 11x7 | 1 | 7.6 | 20.1 | 152 | 5580 | 37.0 | 869 | 30.65 | 77% |
| MAS 11x7 | 1 | 10.8 | 33.1 | 357 | 7410 | 49.1 | 1616 | 57.00 | 72% |
| APC E 11x8.5 | 1 | 7.6 | 18.7 | 142 | 5730 | 46.1 | 710 | 25.04 | 79% |
| APC E 11x8.5 | 1 | 10.9 | 31.7 | 345 | 7590 | 61.1 | 1305 | 46.03 | 73% |
| APC E 12x6 | 1 | 7.6 | 17 | 129 | 5970 | 33.9 | 962 | 33.93 | 83% |
| APC E 12x6 | 1 | 10.9 | 29.7 | 323 | 7800 | 44.3 | 1700 | 59.97 | 75% |
| GWS HD 12x8 | 1 | 7.6 | 20.2 | 153 | 5640 | 42.7 | 1049 | 37.00 | 78% |
| GWS HD 12x8 | 1 | 10.7 | 33 | 353 | 7260 | 55.0 | 1772 | 62.51 | 71% |
| GWS HD 12x8 | 1 | 10.8 | 34 | 367 | 7350 | 55.7 | 1815 | 64.02 | 72% |
