Medusa - 28-32-1500
Specifications
- Type: Inrunner
- Weight: 71.00g (2.50oz)
- Diameter: 28.00mm (1.10in)
- Maximum Amps: 20
Constants
- kV: 1630
- Rm: 0.172
- Io: 0.55
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 0.5 | 16163 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 6x4 | 1 | 6.9 | 4.35 | 30 | 10140 | 38.4 | 192 | 6.77 | 90% |
| APC E 6x4 | 1 | 7.9 | 5.35 | 42 | 11400 | 43.2 | 247 | 8.71 | 89% |
| APC E 6x4 | 1 | 8.9 | 6.5 | 57 | 12660 | 48.0 | 310 | 10.93 | 87% |
| APC E 6x4 | 1 | 9.9 | 7.85 | 77 | 13880 | 52.6 | 376 | 13.26 | 86% |
| APC E 6x4 | 1 | 10.8 | 9.3 | 100 | 14970 | 56.7 | 453 | 15.98 | 85% |
| APC E 6x4 | 1 | 13.5 | 13.5 | 182 | 17700 | 67.0 | 645 | 22.75 | 80% |
| APC E 6x4 | 1 | 14.5 | 15.4 | 223 | 18690 | 70.8 | 721 | 25.43 | 79% |
| APC E 7x5 | 1 | 6.9 | 8.95 | 61 | 8970 | 42.5 | 359 | 12.66 | 80% |
| APC E 7x5 | 1 | 7.8 | 10.95 | 85 | 9960 | 47.2 | 447 | 15.77 | 78% |
| APC E 7x5 | 1 | 8.7 | 13.1 | 113 | 10830 | 51.3 | 534 | 18.84 | 76% |
| APC E 7x5 | 1 | 9.7 | 15.55 | 150 | 11670 | 55.3 | 626 | 22.08 | 74% |
| APC E 7x5 | 1 | 10.7 | 18.2 | 194 | 12330 | 58.4 | 714 | 25.19 | 71% |
| APC Sport 7x7 | 1 | 6.8 | 9.8 | 66 | 8700 | 57.7 | 321 | 11.32 | 78% |
| APC Sport 7x7 | 1 | 7.7 | 12.05 | 92 | 9600 | 63.6 | 395 | 13.93 | 76% |
| APC Sport 7x7 | 1 | 8.7 | 14.4 | 125 | 10410 | 69.0 | 470 | 16.58 | 73% |
| APC Sport 7x7 | 1 | 9.7 | 16.85 | 163 | 11220 | 74.4 | 537 | 18.94 | 71% |
| APC Sport 7x7 | 1 | 10.7 | 19.4 | 207 | 11880 | 78.8 | 606 | 21.38 | 68% |
| GWS HD 8x4 | 1 | 6.8 | 8.6 | 58 | 9000 | 34.1 | 431 | 15.20 | 81% |
| GWS HD 8x4 | 1 | 7.8 | 10.65 | 83 | 9990 | 37.8 | 535 | 18.87 | 79% |
| GWS HD 8x4 | 1 | 8.8 | 13 | 114 | 10920 | 41.4 | 644 | 22.72 | 76% |
| GWS HD 8x4 | 1 | 9.7 | 15.35 | 148 | 11760 | 44.5 | 750 | 26.46 | 74% |
| GWS HD 8x4 | 1 | 10.7 | 17.95 | 192 | 12450 | 47.2 | 860 | 30.34 | 71% |
| APC E 8x4 | 1 | 6.8 | 10.7 | 72 | 8520 | 32.3 | 464 | 16.37 | 77% |
| APC E 8x4 | 1 | 7.7 | 13.15 | 101 | 9330 | 35.3 | 561 | 19.79 | 74% |
| APC E 8x4 | 1 | 8.7 | 15.8 | 137 | 10110 | 38.3 | 667 | 23.53 | 71% |
| APC E 8x4 | 1 | 9.7 | 18.4 | 178 | 10710 | 40.6 | 762 | 26.88 | 68% |
| APC E 8x4 | 1 | 10.6 | 21.1 | 223 | 11310 | 42.8 | 863 | 30.44 | 65% |
| APC E 9x4.5 | 1 | 7 | 14.6 | 102 | 7950 | 33.9 | 609 | 21.48 | 70% |
| APC E 9x4.5 | 1 | 7.1 | 15 | 106 | 8040 | 34.3 | 626 | 22.08 | 69% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 11x7 | 2.83 | 6.9 | 3.5 | 24 | 3660 | 24.3 | 296 | 10.44 | 92% |
| GWS HD 11x7 | 2.83 | 7.9 | 4.45 | 35 | 4170 | 27.6 | 384 | 13.55 | 92% |
| GWS HD 11x7 | 2.83 | 8.9 | 5.35 | 47 | 4620 | 30.6 | 471 | 16.61 | 90% |
| GWS HD 11x7 | 2.83 | 9.9 | 6.35 | 62 | 5040 | 33.4 | 566 | 19.97 | 88% |
| GWS HD 11x7 | 2.83 | 10.9 | 7.45 | 81 | 5460 | 36.2 | 669 | 23.60 | 87% |
| GWS HD 11x7 | 2.83 | 13.5 | 10.5 | 141 | 6600 | 43.8 | 952 | 33.58 | 85% |
| GWS HD 11x7 | 2.83 | 14.5 | 12.2 | 176 | 7020 | 46.5 | 1117 | 39.40 | 84% |
| GWS HD 12x8 | 2.83 | 6.9 | 5 | 34 | 3540 | 26.8 | 399 | 14.07 | 89% |
| GWS HD 12x8 | 2.83 | 7.9 | 6.2 | 48 | 3960 | 30.0 | 502 | 17.71 | 87% |
| GWS HD 12x8 | 2.83 | 8.9 | 7.55 | 67 | 4410 | 33.4 | 617 | 21.76 | 86% |
| GWS HD 12x8 | 2.83 | 9.9 | 9 | 89 | 4800 | 36.4 | 737 | 26.00 | 84% |
| GWS HD 12x8 | 2.83 | 10.8 | 10.45 | 112 | 5190 | 39.3 | 856 | 30.19 | 83% |
| GWS HD 12x8 | 2.83 | 13.5 | 14.9 | 201 | 6150 | 46.6 | 1193 | 42.08 | 79% |
