Mega - RCn 600/20/8


Mega - RCn 600/20/8

Specifications

  • Type: Outrunner
  • Weight: 136.00g (4.80oz)
  • Diameter: 36.00mm (1.42in)
  • Length: 44.80mm (1.76in)
  • Shaft Diameter: 5.00mm (0.20in)
  • Maximum Amps: 35

Constants

  • kV: 887
  • Rm: 0.104
  • Io: 1.9



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 1.8 6040
8 1.8 6935
10 1.9 8665

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 8x6 1 7.4 6.5 48 5970 33.9 238 8.40 91%
APC E 8x6 1 10.1 10.55 106 7860 44.7 444 15.66 88%
APC E 10x7 1 12 21.1 253 8550 56.7 1096 38.66 80%
APC E 11x7 1 10.3 20.5 211 7020 46.5 1124 39.65 77%
APC E 11x7 1 11.8 25 295 7980 52.9 1410 49.74 76%
APC E 12x6 1 7.8 14 109 5700 32.4 852 30.05 82%
APC E 12x6 1 9.6 19.7 189 6540 37.2 1166 41.13 77%
APC E 12x6 1 9.6 20.1 192 6570 37.3 1170 41.27 77%
APC E 12x6 1 10.6 27.9 295 6750 38.4 1440 50.79 72%
APC E 12x6 1 11.1 23.9 265 7440 42.3 1500 52.91 76%
APC E 12x6 1 12.1 29 350 7860 44.7 1710 60.32 73%
APC E 12x6 1 13 31.2 405 8190 46.5 1825 64.37 71%
APC E 12x6 1 13.1 30 393 7920 45.0 1785 62.96 68%
APC E 12x8 1 7.7 16.6 127 5400 40.9 886 31.25 79%
APC E 12x8 1 9.2 22.8 209 6150 46.6 1175 41.45 75%
APC E 12x8 1 9.6 24.4 234 6360 48.2 1256 44.30 75%
APC E 12x8 1 11.1 28.9 320 7050 53.4 1494 52.70 72%
APC E 12x8 1 12 33.4 400 7590 57.5 1770 62.43 71%
APC E 13x8 1 7.1 18.4 130 4860 36.8 908 32.03 77%
APC E 13x8 1 7.6 18.8 142 5130 38.9 980 34.57 76%
APC E 13x8 1 9 25.5 229 5760 43.6 1300 45.86 72%
APC E 13x8 1 9.4 27.8 261 5850 44.3 1380 48.68 70%
APC E 13x8 1 9.8 24.5 240 5640 42.7 1252 44.16 65%
APC E 13x8 1 10.2 31.4 320 6240 47.3 1550 54.67 69%
APC E 13x8 1 10.9 32.2 350 6600 50.0 1739 61.34 68%
APC E 14x8.5 1 7.6 23.2 176 4740 38.1 1187 41.87 70%
APC E 14x8.5 1 10.6 36.9 391 6000 48.3 1900 67.02 64%
