LightFlightRC - 28-47-3 U. Black

Show Similiar


Specifications

  • Type: Inrunner
  • Weight: 118.00g (4.16oz)
  • Diameter: 28.00mm (1.10in)
  • Length: 47.15mm (1.86in)
  • Shaft Diameter: 3.17mm (0.12in)
  • Maximum Amps: 30

Constants

  • kV: 1460
  • Rm: 0.11
  • Io: 0.6



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 0.5 10170
8 0.55 11550
10 0.6 14490

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
Aeronaut 6.5x4 1 7.9 6.4 50 10890 41.2 337 11.89 94%
Aeronaut 6.5x4 1 11.9 12.5 148 15540 58.9 701 24.73 89%
APC Sport 7x4 1 11.7 15.2 177 14520 55.0 813 28.68 85%
APC E 7x5 1 7.7 10.35 79 9870 46.7 451 15.91 88%
APC E 7x5 1 11.7 20.3 237 13560 64.2 893 31.50 79%
APC Sport 7x7 1 7.8 11.4 88 9750 64.6 418 14.74 86%
APC Sport 7x7 1 11.5 20.6 236 13270 88.0 771 27.20 79%
APC Sport 7x7 1 11.6 21 243 12930 85.7 776 27.37 76%
Aeronaut 7x7 1 7.7 12.5 96 9480 62.8 354 12.49 84%
Aeronaut 7x7 1 11.5 22.72 261 12840 85.1 655 23.10 76%
APC E 8x4 1 7.7 12.35 95 9390 35.6 592 20.88 84%
APC E 8x4 1 11.6 25 290 12300 46.6 1100 38.80 73%
APC E 8x6 1 7.9 18 142 8760 49.8 637 22.47 76%
APC E 8x6 1 11.4 32.1 365 10800 61.4 1025 36.16 65%
Aeronaut Carbon 8.5x5 1 7.8 13.5 105 9390 44.5 625 22.05 82%
Aeronaut Carbon 8.5x5 1 11.6 25 290 12360 58.5 1106 39.01 73%
APC E 9x4.5 1 7.9 17.1 135 8880 37.8 798 28.15 77%
APC E 10x5 1 7.8 21.2 165 8040 38.1 920 32.45 71%
APC E 10x5 1 11 33.6 369 9750 46.2 1426 50.30 61%
GWS HD 10x6 1 7.6 19.3 146 7950 45.2 862 30.41 72%
GWS HD 10x6 1 11.1 33.1 367 10080 57.3 1471 51.89 62%
