GPS - B20-30-A
Specifications
- Type: Inrunner
- Weight: 42.00g (1.48oz)
- Diameter: 20.15mm (0.79in)
- Length: 37.15mm (1.46in)
- Shaft Diameter: 2.30mm (0.09in)
- Maximum Amps: 15
Constants
- kV: 5760
- Rm: 0.186
- Io: 1.26
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 8.03 | 0.85 | 42780 |
| 10.035 | 1.26 | 53400 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 7x5 | 4.22 | 6.9 | 6.5 | 44 | 7800 | 36.9 | 271 | 9.56 | 83% |
| APC E 7x5 | 4.22 | 7.9 | 7.9 | 62 | 8760 | 41.5 | 349 | 12.31 | 81% |
| APC E 7x5 | 4.22 | 8.9 | 9.7 | 86 | 9720 | 46.0 | 434 | 15.31 | 80% |
| APC E 7x5 | 4.22 | 9.9 | 11.5 | 113 | 10650 | 50.4 | 529 | 18.66 | 79% |
| APC E 7x5 | 4.22 | 10.9 | 13.4 | 146 | 11430 | 54.1 | 611 | 21.55 | 77% |
| GWS HD 8x4 | 4.22 | 6.9 | 6.5 | 44 | 7770 | 29.4 | 318 | 11.22 | 83% |
| GWS HD 8x4 | 4.22 | 7.9 | 7.9 | 62 | 8730 | 33.1 | 412 | 14.53 | 81% |
| GWS HD 8x4 | 4.22 | 8.9 | 9.65 | 85 | 9720 | 36.8 | 510 | 17.99 | 80% |
| GWS HD 8x4 | 4.22 | 9.9 | 11.5 | 113 | 10650 | 40.3 | 620 | 21.87 | 79% |
| GWS HD 8x4 | 4.22 | 10.9 | 13.6 | 148 | 11430 | 43.3 | 720 | 25.40 | 77% |
