LightFlightRC - 28-37-2 Silver #1
Specifications
- Type: Inrunner
- Weight: 76.00g (2.68oz)
- Diameter: 28.00mm (1.10in)
- Length: 37.15mm (1.46in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 25
Constants
- kV: 4184
- Rm: 0.084
- Io: 2.33
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10.03 | 2.33 | 40380 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| Aeronaut 7x7 | 3.167 | 6.9 | 10.1 | 69 | 8070 | 53.5 | 254 | 8.96 | 89% |
| Aeronaut 7x7 | 3.167 | 7.9 | 12.6 | 99 | 9060 | 60.1 | 328 | 11.57 | 87% |
| Aeronaut 7x7 | 3.167 | 8.9 | 15.2 | 135 | 10020 | 66.4 | 401 | 14.14 | 85% |
| Aeronaut 7x7 | 3.167 | 9.9 | 18.2 | 180 | 11010 | 73.0 | 486 | 17.14 | 84% |
| Aeronaut 7x7 | 3.167 | 10.9 | 21 | 228 | 12030 | 79.7 | 576 | 20.32 | 84% |
| GWS HD 8x4 | 3.167 | 6.9 | 8.25 | 56 | 8250 | 31.2 | 360 | 12.70 | 91% |
| GWS HD 8x4 | 3.167 | 7.9 | 10.5 | 82 | 9300 | 35.2 | 458 | 16.16 | 89% |
| GWS HD 8x4 | 3.167 | 8.9 | 12.7 | 113 | 10350 | 39.2 | 575 | 20.28 | 88% |
| GWS HD 8x4 | 3.167 | 9.9 | 14.7 | 145 | 11430 | 43.3 | 710 | 25.04 | 87% |
| GWS HD 8x4 | 3.167 | 10.8 | 16.9 | 182 | 12390 | 46.9 | 840 | 29.63 | 87% |
| APC E 8x4 | 3.167 | 6.9 | 10.1 | 69 | 8160 | 30.9 | 437 | 15.41 | 90% |
| APC E 8x4 | 3.167 | 7.9 | 12.5 | 98 | 9180 | 34.8 | 559 | 19.72 | 88% |
| APC E 8x4 | 3.167 | 8.9 | 14.95 | 133 | 10170 | 38.5 | 698 | 24.62 | 86% |
| APC E 8x4 | 3.167 | 9.9 | 18.25 | 180 | 11130 | 42.2 | 845 | 29.81 | 85% |
| APC E 8x4 | 3.167 | 10.9 | 21 | 228 | 11940 | 45.2 | 984 | 34.71 | 83% |
| APC E 8x6 | 3.167 | 6.8 | 14.35 | 97 | 7710 | 43.8 | 454 | 16.01 | 86% |
| APC E 8x6 | 3.167 | 7.8 | 18.2 | 141 | 8550 | 48.6 | 576 | 20.32 | 83% |
| GWS HD 9x5 | 3.167 | 6.9 | 13.9 | 95 | 7800 | 36.9 | 612 | 21.59 | 86% |
| GWS HD 9x5 | 3.167 | 7.8 | 17.5 | 136 | 8610 | 40.8 | 757 | 26.70 | 84% |
