LightFlightRC - 28-37-3 Black
Specifications
- Type: Inrunner
- Weight: 83.00g (2.93oz)
- Diameter: 28.00mm (1.10in)
- Length: 37.15mm (1.46in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 25
Constants
- kV: 2660
- Rm: 0.12
- Io: 1.04
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 1.04 | 26220 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 4.1x4.1 | 1 | 6.9 | 5.8 | 40 | 16860 | 65.5 | 164 | 5.78 | 92% |
| APC E 4.1x4.1 | 1 | 7.9 | 7.1 | 56 | 18990 | 73.7 | 208 | 7.34 | 90% |
| APC E 4.1x4.1 | 1 | 8.9 | 8.7 | 77 | 20970 | 81.4 | 255 | 8.99 | 89% |
| APC E 4.1x4.1 | 1 | 9.9 | 10.3 | 101 | 23010 | 89.3 | 310 | 10.93 | 87% |
| APC E 4.1x4.1 | 1 | 10.9 | 12 | 130 | 24900 | 96.7 | 364 | 12.84 | 86% |
| APC E 4.1x4.1 | 1 | 14.5 | 19.1 | 276 | 31530 | 122.4 | 594 | 20.95 | 82% |
| Zagi Carbon 5.1x4.9 | 1 | 6.9 | 11.1 | 76 | 15150 | 70.3 | 327 | 11.53 | 83% |
| Zagi Carbon 5.1x4.9 | 1 | 7.8 | 13.65 | 106 | 16890 | 78.4 | 411 | 14.50 | 81% |
| Zagi Carbon 5.1x4.9 | 1 | 8.8 | 16.25 | 143 | 18360 | 85.2 | 484 | 17.07 | 78% |
| Zagi Carbon 5.1x4.9 | 1 | 9.8 | 19.3 | 189 | 19920 | 92.4 | 577 | 20.35 | 76% |
| Zagi Carbon 5.1x4.9 | 1 | 10.7 | 22.3 | 238 | 21210 | 98.4 | 657 | 23.17 | 75% |
| APC E 5.25x6.25 | 1 | 7.8 | 19.2 | 149 | 14940 | 88.4 | 326 | 11.50 | 72% |
| APC E 5.25x6.25 | 1 | 11.1 | 31.2 | 346 | 18960 | 112.2 | 518 | 18.27 | 64% |
| APC E 6x4 | 1 | 7.8 | 16.6 | 129 | 15930 | 60.3 | 542 | 19.12 | 77% |
| APC E 6x4 | 1 | 11.2 | 28.4 | 318 | 20490 | 77.6 | 932 | 32.88 | 69% |
| APC E 6x5.5 | 1 | 7.7 | 20.8 | 160 | 14340 | 74.7 | 490 | 17.28 | 70% |
