Grayson - Mega Jet 21
Specifications
- Type: Outrunner
- Weight: 60.00g (2.12oz)
- Maximum Amps: 25
Constants
- kV: 2035
- Rm: 0.09
- Io: 2.25
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 2.25 | 19950 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 5x5 | 1 | 6.9 | 7.8 | 53 | 12960 | 61.4 | 169 | 5.96 | 92% |
| APC E 5x5 | 1 | 7.9 | 9.6 | 75 | 14580 | 69.0 | 220 | 7.76 | 91% |
| APC E 5x5 | 1 | 8.9 | 11.4 | 101 | 16140 | 76.4 | 269 | 9.49 | 89% |
| APC E 5x5 | 1 | 9.8 | 13.4 | 131 | 17760 | 84.1 | 328 | 11.57 | 89% |
| APC E 5x5 | 1 | 10.6 | 14.95 | 158 | 18750 | 88.8 | 369 | 13.02 | 87% |
| APC E 5x5 | 1 | 10.8 | 15.4 | 166 | 19110 | 90.5 | 384 | 13.55 | 87% |
| Zagi Carbon 5.1x4.9 | 1 | 6.9 | 7.6 | 52 | 12960 | 60.1 | 238 | 8.40 | 92% |
| Zagi Carbon 5.1x4.9 | 1 | 7.9 | 9.3 | 73 | 14550 | 67.5 | 302 | 10.65 | 91% |
| Zagi Carbon 5.1x4.9 | 1 | 8.9 | 11.2 | 99 | 16140 | 74.9 | 378 | 13.33 | 89% |
| Zagi Carbon 5.1x4.9 | 1 | 9.8 | 13.2 | 129 | 17670 | 82.0 | 447 | 15.77 | 89% |
| Zagi Carbon 5.1x4.9 | 1 | 10.8 | 15.8 | 170 | 19050 | 88.4 | 528 | 18.62 | 87% |
| Graupner CAM Speed 5.5x5.5 | 1 | 6.9 | 10.15 | 70 | 12480 | 65.0 | 260 | 9.17 | 89% |
| Graupner CAM Speed 5.5x5.5 | 1 | 7.8 | 12.55 | 97 | 13980 | 72.8 | 331 | 11.68 | 88% |
| Graupner CAM Speed 5.5x5.5 | 1 | 8.8 | 15 | 132 | 15420 | 80.3 | 405 | 14.29 | 86% |
| Graupner CAM Speed 5.5x5.5 | 1 | 9.8 | 17.6 | 172 | 16860 | 87.8 | 477 | 16.83 | 85% |
| Graupner CAM Speed 5.5x5.5 | 1 | 10.7 | 20.1 | 215 | 18150 | 94.5 | 555 | 19.58 | 83% |
| APC E 6x4 | 1 | 6.9 | 9.3 | 64 | 12690 | 48.1 | 316 | 11.15 | 90% |
| APC E 6x4 | 1 | 7.8 | 11.45 | 89 | 14220 | 53.9 | 400 | 14.11 | 90% |
| APC E 6x4 | 1 | 8.8 | 13.8 | 121 | 15900 | 60.2 | 493 | 17.39 | 89% |
| APC E 6x4 | 1 | 9.8 | 16.25 | 159 | 17160 | 65.0 | 597 | 21.06 | 86% |
| APC E 6x4 | 1 | 10.8 | 18.9 | 204 | 18570 | 70.3 | 709 | 25.01 | 84% |
| HZ 6x4 | 1 | 6.9 | 10.1 | 69 | 12540 | 47.5 | 338 | 11.92 | 89% |
| HZ 6x4 | 1 | 7.8 | 12.2 | 95 | 13980 | 53.0 | 423 | 14.92 | 88% |
| HZ 6x4 | 1 | 8.8 | 14.6 | 128 | 15450 | 58.5 | 524 | 18.48 | 86% |
| HZ 6x4 | 1 | 9.8 | 17.6 | 172 | 16830 | 63.8 | 637 | 22.47 | 84% |
| HZ 6x4 | 1 | 10.7 | 20.2 | 216 | 18150 | 68.8 | 734 | 25.89 | 83% |
| Aeronaut 6x5 | 1 | 6.8 | 11.45 | 77 | 12270 | 58.1 | 336 | 11.85 | 89% |
| Aeronaut 6x5 | 1 | 7.8 | 13.85 | 108 | 13710 | 64.9 | 416 | 14.67 | 86% |
| Aeronaut 6x5 | 1 | 8.7 | 16.5 | 143 | 15090 | 71.5 | 504 | 17.78 | 85% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| Aeronaut 6x5 | 1 | 9.7 | 19.1 | 185 | 16470 | 78.0 | 595 | 20.99 | 83% |
| Aeronaut 6x5 | 1 | 10.7 | 22.3 | 238 | 17850 | 84.5 | 702 | 24.76 | 82% |
| APC E 6x5.5 | 1 | 6.8 | 12.65 | 86 | 12060 | 62.8 | 328 | 11.57 | 87% |
| APC E 6x5.5 | 1 | 7.8 | 15.1 | 117 | 13500 | 70.3 | 419 | 14.78 | 85% |
| APC E 6x5.5 | 1 | 8.7 | 17.6 | 153 | 14850 | 77.3 | 507 | 17.88 | 84% |
| APC E 6x5.5 | 1 | 9.7 | 20.5 | 198 | 16170 | 84.2 | 606 | 21.38 | 82% |
| APC E 6x5.5 | 1 | 10.7 | 24.1 | 257 | 17460 | 90.9 | 702 | 24.76 | 80% |
| Graupner CAM Speed 6x6 | 1 | 6.8 | 13.4 | 91 | 11970 | 68.0 | 308 | 10.86 | 87% |
| Graupner CAM Speed 6x6 | 1 | 7.8 | 15.4 | 120 | 13440 | 76.4 | 394 | 13.90 | 85% |
| Graupner CAM Speed 6x6 | 1 | 8.7 | 18.2 | 158 | 14760 | 83.9 | 472 | 16.65 | 83% |
| Graupner CAM Speed 6x6 | 1 | 9.7 | 21.1 | 204 | 16080 | 91.4 | 562 | 19.82 | 81% |
| Aeronaut 6.5x4 | 1 | 6.8 | 11.4 | 77 | 12240 | 46.4 | 424 | 14.96 | 88% |
| Aeronaut 6.5x4 | 1 | 7.8 | 13.95 | 108 | 13710 | 51.9 | 533 | 18.80 | 86% |
| Aeronaut 6.5x4 | 1 | 8.7 | 16.65 | 144 | 15030 | 56.9 | 648 | 22.86 | 85% |
| Aeronaut 6.5x4 | 1 | 9.7 | 20 | 194 | 16320 | 61.8 | 773 | 27.27 | 83% |
| Aeronaut 6.5x4 | 1 | 10.7 | 22.7 | 242 | 17550 | 66.5 | 894 | 31.53 | 81% |
| Graupner CAM Speed 6.5x6.5 | 1 | 6.8 | 15.9 | 108 | 11400 | 70.2 | 360 | 12.70 | 82% |
| Graupner CAM Speed 6.5x6.5 | 1 | 11.1 | 32.8 | 364 | 16470 | 101.4 | 759 | 26.77 | 73% |
