Suppo - A2217/09
Specifications
- Type: Outrunner
- Weight: 63.00g (2.22oz)
- Diameter: 27.60mm (1.09in)
- Length: 31.70mm (1.25in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 25
Constants
- kV: 1070
- Rm: 0.194
- Io: 0.85
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 10 | 0.85 | 10680 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 8x4 | 1 | 6.9 | 3.75 | 25 | 6840 | 25.9 | 241 | 8.50 | 93% |
| GWS HD 8x4 | 1 | 7.9 | 4.6 | 36 | 7680 | 29.1 | 306 | 10.79 | 91% |
| GWS HD 8x4 | 1 | 8.9 | 5.45 | 48 | 8490 | 32.2 | 379 | 13.37 | 89% |
| GWS HD 8x4 | 1 | 9.9 | 6.5 | 64 | 9330 | 35.3 | 464 | 16.37 | 88% |
| GWS HD 8x4 | 1 | 10.9 | 7.45 | 81 | 10110 | 38.3 | 547 | 19.29 | 87% |
| GWS HD 9x5 | 1 | 6.9 | 6.3 | 43 | 6330 | 30.0 | 382 | 13.47 | 86% |
| GWS HD 9x5 | 1 | 7.9 | 7.7 | 60 | 7020 | 33.2 | 484 | 17.07 | 83% |
| GWS HD 9x5 | 1 | 8.9 | 9.25 | 82 | 7770 | 36.8 | 595 | 20.99 | 82% |
| GWS HD 9x5 | 1 | 9.9 | 10.75 | 106 | 8430 | 39.9 | 701 | 24.73 | 80% |
| GWS HD 9x5 | 1 | 10.9 | 12.4 | 135 | 9030 | 42.8 | 814 | 28.71 | 77% |
| GWS HD 9x7.5 | 1 | 6.9 | 9.6 | 66 | 5730 | 40.7 | 389 | 13.72 | 78% |
| GWS HD 9x7.5 | 1 | 7.9 | 11.6 | 91 | 6300 | 44.7 | 475 | 16.76 | 75% |
| GWS HD 9x7.5 | 1 | 8.9 | 13.65 | 121 | 6840 | 48.6 | 559 | 19.72 | 72% |
| GWS HD 9x7.5 | 1 | 9.7 | 15.6 | 151 | 7320 | 52.0 | 644 | 22.72 | 71% |
| APC E 10x5 | 1 | 6.9 | 8.3 | 57 | 5970 | 28.3 | 476 | 16.79 | 81% |
| APC E 10x5 | 1 | 7.9 | 10 | 79 | 6570 | 31.1 | 588 | 20.74 | 78% |
| APC E 10x5 | 1 | 8.9 | 11.75 | 104 | 7170 | 34.0 | 698 | 24.62 | 75% |
| APC E 10x5 | 1 | 9.9 | 13.85 | 137 | 7740 | 36.6 | 825 | 29.10 | 73% |
| APC E 10x5 | 1 | 10.8 | 15.7 | 169 | 8250 | 39.1 | 945 | 33.33 | 71% |
| GWS HD 10x6 | 1 | 6.9 | 8.4 | 57 | 5940 | 33.8 | 480 | 16.93 | 80% |
| GWS HD 10x6 | 1 | 7.9 | 10.15 | 80 | 6540 | 37.2 | 592 | 20.88 | 77% |
| GWS HD 10x6 | 1 | 8.9 | 11.9 | 105 | 7170 | 40.7 | 707 | 24.94 | 75% |
| GWS HD 10x6 | 1 | 9.9 | 14 | 138 | 7770 | 44.1 | 835 | 29.45 | 73% |
| GWS HD 10x6 | 1 | 10.8 | 15.9 | 171 | 8250 | 46.9 | 949 | 33.47 | 71% |
| GWS HD 10x8 | 1 | 6.9 | 12.2 | 84 | 5220 | 39.5 | 479 | 16.90 | 71% |
| GWS HD 10x8 | 1 | 7.8 | 14.45 | 112 | 5700 | 43.2 | 572 | 20.18 | 68% |
| GWS HD 10x8 | 1 | 8.8 | 17 | 149 | 6180 | 46.8 | 672 | 23.70 | 66% |
| GWS HD 10x8 | 1 | 9.7 | 19.3 | 187 | 6540 | 49.5 | 754 | 26.60 | 63% |
| GWS HD 10x8 | 1 | 10.7 | 21.4 | 228 | 6870 | 52.0 | 842 | 29.70 | 60% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| APC SF 11x4.7 | 1 | 6.8 | 12.4 | 84 | 5190 | 23.1 | 648 | 22.86 | 71% |
| APC SF 11x4.7 | 1 | 7.8 | 14.85 | 115 | 5640 | 25.1 | 788 | 27.80 | 68% |
| APC SF 11x4.7 | 1 | 8.7 | 17.5 | 152 | 6060 | 27.0 | 927 | 32.70 | 65% |
| APC SF 11x4.7 | 1 | 9.7 | 19.9 | 193 | 6360 | 28.3 | 1045 | 36.86 | 61% |
| APC SF 11x4.7 | 1 | 10.7 | 22.1 | 236 | 6720 | 29.9 | 1168 | 41.20 | 59% |
| APC E 11x5.5 | 1 | 6.9 | 10.2 | 70 | 5580 | 29.1 | 575 | 20.28 | 76% |
| APC E 11x5.5 | 1 | 7.8 | 12.25 | 95 | 6090 | 31.7 | 700 | 24.69 | 73% |
| APC E 11x5.5 | 1 | 8.8 | 14.4 | 126 | 6600 | 34.4 | 828 | 29.21 | 70% |
| APC E 11x5.5 | 1 | 9.8 | 16.75 | 164 | 7080 | 36.9 | 960 | 33.86 | 68% |
| APC E 11x5.5 | 1 | 10.8 | 18.8 | 203 | 7470 | 38.9 | 1080 | 38.10 | 65% |
Comments
rgoble on 2009-01-02 14:25:25
This motor is also sold under another brand name as the Grayson-Welgard - 2217/09
