Suppo - H2212/5.5
Specifications
- Type: Outrunner
- Weight: 50.00g (1.76oz)
- Diameter: 27.60mm (1.09in)
- Length: 28.80mm (1.13in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 45
Constants
- kV: 3875
- Rm: 0.07
- Io: 3
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 2.35 | 26550 |
| 8 | 2.5 | 30220 |
| 10 | 3 | 37700 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 8x4 | 2.43 | 7.8 | 14.2 | 110 | 10500 | 39.8 | 594 | 20.95 | 84% |
| GWS HD 8x4 | 2.43 | 10.9 | 25.1 | 273 | 13800 | 52.3 | 1064 | 37.53 | 79% |
| APC E 9x4.5 | 2.43 | 7.4 | 22.1 | 163 | 9240 | 39.4 | 849 | 29.95 | 78% |
| APC E 9x4.5 | 2.43 | 10.8 | 40 | 432 | 12000 | 51.1 | 1536 | 54.18 | 70% |
| GWS HD 9x5 | 2.43 | 7.4 | 23.1 | 170 | 9060 | 42.9 | 835 | 29.45 | 77% |
| GWS HD 9x5 | 2.43 | 10.1 | 36.2 | 365 | 11520 | 54.5 | 1395 | 49.21 | 72% |
| GWS HD 10x6 | 2.43 | 10.6 | 46.2 | 489 | 10890 | 61.9 | 1682 | 59.33 | 64% |
