ARC - 20-27-80
Specifications
- Type: Inrunner
- Weight: 32.00g (1.13oz)
- Diameter: 20.00mm (0.79in)
- Length: 27.00mm (1.06in)
- Shaft Diameter: 2.00mm (0.08in)
- Maximum Amps: 8
Constants
- kV: 4760
- Rm: 0.136
- Io: 0.8
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 6 | 0.6 | 28380 |
| 8 | 0.7 | 37650 |
| 10 | 0.8 | 47160 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 7x3.5 | 3 | 6.9 | 4.35 | 30 | 9570 | 31.7 | 198 | 6.98 | 87% |
| GWS HD 7x3.5 | 3 | 7 | 4.35 | 30 | 9630 | 31.9 | 203 | 7.16 | 87% |
| GWS HD 7x3.5 | 3 | 7.9 | 5.25 | 41 | 10860 | 36.0 | 263 | 9.28 | 87% |
| GWS HD 7x3.5 | 3 | 7.9 | 5.3 | 41 | 10890 | 36.1 | 259 | 9.14 | 87% |
| GWS HD 7x3.5 | 3 | 8.9 | 6.45 | 57 | 12090 | 40.1 | 325 | 11.46 | 86% |
| GWS HD 7x3.5 | 3 | 8.9 | 6.35 | 56 | 12090 | 40.1 | 334 | 11.78 | 86% |
| GWS HD 7x3.5 | 3 | 9.9 | 7.55 | 74 | 13320 | 44.1 | 411 | 14.50 | 85% |
| GWS HD 7x3.5 | 3 | 10.9 | 8.85 | 96 | 14460 | 47.9 | 492 | 17.35 | 84% |
| GWS HD 7x3.5 | 3 | 10.9 | 9 | 98 | 14490 | 48.0 | 476 | 16.79 | 84% |
