Motrolfly - 2205-2800



Specifications

  • Type: Outrunner
  • Weight: 32.00g (1.13oz)
  • Maximum Amps: 20

Constants

  • kV: 2840
  • Rm: 0.12
  • Io: 2.25



Io Test Data

Dr Kiwi test results
Volts Amps RPM
10 2.25 27630

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 4.1x4.1 1 6.9 7.75 53 17490 67.9 180 6.35 89%
APC E 4.1x4.1 1 7.4 8.65 64 18630 72.3 205 7.23 89%
APC E 4.1x4.1 1 7.9 9.35 73 19620 76.2 225 7.94 87%
APC E 4.1x4.1 1 8.8 11.3 99 21600 83.9 278 9.81 86%
APC E 4.1x4.1 1 9.8 13.05 127 23520 91.3 331 11.68 85%
APC E 4.1x4.1 1 10.8 15.15 163 25410 98.7 390 13.76 83%
APC E 4.5x4.1 1 6.9 9.7 66 16950 65.8 239 8.43 86%
APC E 4.5x4.1 1 7.4 11 81 18090 70.2 276 9.74 86%
APC E 4.5x4.1 1 7.8 11.8 92 18810 73.0 299 10.55 85%
APC E 4.5x4.1 1 8.8 14 123 20670 80.2 362 12.77 83%
APC E 4.5x4.1 1 9.7 16.3 158 22350 86.8 428 15.10 81%
APC E 4.5x4.1 1 10.7 18.7 200 24000 93.2 486 17.14 79%
Graupner CAM 4.7x4.7 1 6.8 12.1 82 16170 72.0 258 9.10 84%
Graupner CAM 4.7x4.7 1 7.4 13.6 100 17280 76.9 298 10.51 82%
Graupner CAM 4.7x4.7 1 7.8 14.4 112 17910 79.7 317 11.18 81%
Graupner CAM 4.7x4.7 1 8.8 17.1 150 19260 85.7 383 13.51 77%
Graupner CAM 4.7x4.7 1 9.7 19.9 193 20940 93.2 449 15.84 76%
