Grayson - Super Cruise #2

Show Similiar


Specifications

  • Type: Outrunner
  • Weight: 55.00g (1.94oz)
  • Maximum Amps: 40

Constants

  • kV: 2560
  • Rm: 0.114
  • Io: 1.45



Io Test Data

Dr Kiwi test results
Volts Amps RPM
10 1.45 25200

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 4.1x4.1 1 13.8 17.3 238 28920 112.3 488 17.21 82%
APC E 4.5x4.1 1 13.8 22.1 304 27420 106.5 592 20.88 78%
APC E 4.7x4.25 1 6.9 8.7 60 15420 62.1 210 7.41 87%
APC E 4.7x4.25 1 7.9 10.55 83 17300 69.6 272 9.59 86%
APC E 4.7x4.25 1 8.8 13.8 121 18660 75.1 313 11.04 83%
APC E 4.7x4.25 1 9.8 14.55 142 20910 84.2 399 14.07 83%
APC E 4.7x4.25 1 10.8 17.15 185 22560 90.8 469 16.54 82%
APC E 4.75x5.5 1 13.1 28.2 369 23550 122.7 530 18.70 70%
APC E 5x5 1 6.8 11.2 76 14670 69.5 214 7.55 84%
APC E 5x5 1 7.8 13.65 106 16380 77.6 268 9.45 82%
APC E 5x5 1 8.8 16.5 145 18000 85.2 330 11.64 80%
APC E 5x5 1 9.8 19.2 188 19440 92.0 388 13.69 77%
APC E 5x5 1 10.7 21.9 234 20940 99.2 449 15.84 76%
Zagi Carbon 5.1x4.9 1 6.8 11.2 76 14730 68.3 307 10.83 85%
Zagi Carbon 5.1x4.9 1 7.8 13.7 106 16440 76.3 385 13.58 82%
Zagi Carbon 5.1x4.9 1 8.8 16.35 143 17940 83.2 466 16.44 80%
Zagi Carbon 5.1x4.9 1 9.8 19.1 187 19560 90.8 546 19.26 78%
Zagi Carbon 5.1x4.9 1 10.7 22.2 237 20910 97.0 635 22.40 76%
Zagi Carbon 5.1x4.9 1 13.2 29.4 388 23460 108.9 815 28.75 69%
APC E 5.25x6.25 1 11.4 31.4 357 19440 115.1 526 18.55 67%
APC E 5.5x4.5 1 6.8 13.1 89 14280 60.9 295 10.41 82%
APC E 5.5x4.5 1 7.8 15.85 123 15840 67.5 367 12.95 79%
APC E 5.5x4.5 1 8.7 18.65 162 17280 73.6 449 15.84 78%
APC E 5.5x4.5 1 9.7 21.5 208 18630 79.4 529 18.66 75%
APC E 5.5x4.5 1 10.6 24.8 262 19920 84.9 611 21.55 73%
