UH - 2000 (Lance Ferry)
Specifications
- Type: Outrunner
- Weight: 16.00g (0.56oz)
- Shaft Diameter: 2.00mm (0.08in)
- Maximum Amps: 4
Constants
- kV: 2150
- Rm: 0.92
- Io: 0.65
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.6 | 13950 |
| 8 | 0.6 | 15930 |
| 10 | 0.65 | 20160 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS DD 4x2.5 | 1 | 7 | 1.6 | 11 | 12210 | 28.9 | 68 | 2.40 | 81% |
| GWS DD 4x2.5 | 1 | 7.4 | 1.7 | 12 | 12780 | 30.3 | 75 | 2.65 | 80% |
| GWS DD 4x2.5 | 1 | 7.9 | 1.85 | 14 | 13560 | 32.1 | 84 | 2.96 | 80% |
| GWS DD 4x2.5 | 1 | 8.9 | 2.15 | 19 | 14940 | 35.4 | 102 | 3.60 | 78% |
| GWS DD 4x2.5 | 1 | 9.9 | 2.45 | 24 | 16230 | 38.4 | 122 | 4.30 | 76% |
| GWS DD 4x2.5 | 1 | 10.9 | 2.75 | 29 | 17490 | 41.4 | 140 | 4.94 | 75% |
| Gunther 4.92x4.33 | 1 | 7 | 3.2 | 22 | 8970 | 36.8 | 114 | 4.02 | 60% |
| Gunther 4.92x4.33 | 1 | 7.4 | 3.4 | 25 | 9240 | 37.9 | 123 | 4.34 | 58% |
| GWS HD 5x3 | 1 | 7 | 2.3 | 16 | 10800 | 30.7 | 104 | 3.67 | 72% |
| GWS HD 5x3 | 1 | 7.4 | 2.45 | 18 | 11310 | 32.1 | 115 | 4.06 | 71% |
| GWS HD 5x3 | 1 | 7.9 | 2.7 | 21 | 12120 | 34.4 | 130 | 4.59 | 71% |
| GWS HD 5x3 | 1 | 8.9 | 3.05 | 27 | 12930 | 36.7 | 154 | 5.43 | 68% |
| GWS HD 5x3 | 1 | 9.9 | 3.5 | 34 | 14160 | 40.2 | 182 | 6.42 | 67% |
| GWS HD 5x3 | 1 | 10.9 | 3.9 | 42 | 14820 | 42.1 | 205 | 7.23 | 63% |
| GWS HD 5x4.3 | 1 | 7 | 3 | 21 | 9030 | 36.8 | 107 | 3.77 | 60% |
| GWS HD 5x4.3 | 1 | 7.4 | 3.3 | 24 | 9510 | 38.7 | 119 | 4.20 | 60% |
| GWS HD 6x3 | 1 | 7 | 3.1 | 21 | 9180 | 26.1 | 138 | 4.87 | 61% |
| GWS HD 6x3 | 1 | 7.4 | 3.25 | 24 | 9540 | 27.1 | 148 | 5.22 | 60% |
| GWS HD 7x3.5 | 1 | 7 | 3.55 | 24 | 8160 | 27.1 | 153 | 5.40 | 54% |
