Grayson - SuperMegaJet V2
Specifications
- Type: Outrunner
- Weight: 74.00g (2.61oz)
- Maximum Amps: 30
Constants
- kV: 2360
- Rm: 0.08
- Io: 4.7
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 6.9 | 3.7 | 15810 |
| 7.9 | 4 | 18000 |
| 9.9 | 4.7 | 22440 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 4.1x4.1 | 1 | 6.9 | 7.3 | 50 | 14940 | 58.0 | 124 | 4.37 | 92% |
| APC E 4.1x4.1 | 1 | 7.9 | 8.7 | 68 | 16890 | 65.6 | 159 | 5.61 | 91% |
| APC E 4.1x4.1 | 1 | 8.8 | 10.2 | 89 | 19020 | 73.8 | 201 | 7.09 | 92% |
| APC E 4.1x4.1 | 1 | 9.8 | 11.5 | 112 | 20970 | 81.4 | 244 | 8.61 | 91% |
| APC E 4.1x4.1 | 1 | 10.8 | 13.3 | 143 | 22950 | 89.1 | 294 | 10.37 | 90% |
| APC E 4.7x4.25 | 1 | 6.8 | 9.2 | 62 | 14730 | 59.3 | 205 | 7.23 | 92% |
| APC E 4.7x4.25 | 1 | 7.8 | 11.1 | 86 | 16620 | 66.9 | 265 | 9.35 | 90% |
| APC E 4.7x4.25 | 1 | 8.8 | 13.2 | 116 | 18420 | 74.1 | 320 | 11.29 | 89% |
| APC E 4.7x4.25 | 1 | 9.8 | 15.55 | 152 | 20220 | 81.4 | 396 | 13.97 | 87% |
| APC E 4.7x4.25 | 1 | 10.7 | 18 | 192 | 21930 | 88.3 | 462 | 16.30 | 87% |
| APC E 4.75x5.5 | 1 | 6.8 | 11.65 | 79 | 14100 | 73.4 | 186 | 6.56 | 88% |
| APC E 4.75x5.5 | 1 | 7.8 | 14.15 | 110 | 15900 | 82.8 | 235 | 8.29 | 86% |
| APC E 4.75x5.5 | 1 | 8.7 | 17.6 | 153 | 17550 | 91.4 | 284 | 10.02 | 85% |
| APC E 4.75x5.5 | 1 | 9.7 | 19.6 | 190 | 19290 | 100.5 | 338 | 11.92 | 84% |
| APC E 4.75x5.5 | 1 | 10.7 | 22.6 | 241 | 20910 | 108.9 | 411 | 14.50 | 83% |
| Zagi Carbon 5.1x4.9 | 1 | 6.8 | 11.3 | 76 | 14100 | 65.4 | 272 | 9.59 | 88% |
| Zagi Carbon 5.1x4.9 | 1 | 7.8 | 13.5 | 105 | 15900 | 73.8 | 352 | 12.42 | 86% |
| Zagi Carbon 5.1x4.9 | 1 | 8.7 | 16.3 | 141 | 17580 | 81.6 | 423 | 14.92 | 86% |
| Zagi Carbon 5.1x4.9 | 1 | 9.7 | 19 | 184 | 19470 | 90.3 | 534 | 18.84 | 85% |
| Zagi Carbon 5.1x4.9 | 1 | 10.6 | 21.6 | 228 | 21000 | 97.4 | 617 | 21.76 | 84% |
| Zagi Carbon 5.1x4.9 | 1 | 13.1 | 28.3 | 370 | 24920 | 115.6 | 810 | 28.57 | 81% |
| APC E 6x4 | 1 | 7.8 | 16.55 | 129 | 15330 | 58.1 | 470 | 16.58 | 83% |
| APC E 6x4 | 1 | 10.7 | 27.3 | 292 | 20130 | 76.2 | 816 | 28.78 | 80% |
| APC E 6x4 | 1 | 10.8 | 27.5 | 297 | 20220 | 76.6 | 830 | 29.28 | 79% |
| APC E 6x4 | 1 | 11.3 | 29.5 | 333 | 20730 | 78.5 | 879 | 31.01 | 78% |
| APC E 6x4 | 1 | 12.6 | 34.1 | 429 | 22140 | 83.9 | 1000 | 35.27 | 74% |
| APC E 6x4 | 1 | 12.6 | 35.6 | 448 | 22920 | 86.8 | 1060 | 37.39 | 77% |
| APC E 6x4 | 1 | 13.1 | 36.5 | 478 | 23130 | 87.6 | 1090 | 38.45 | 75% |
| APC E 6x4 | 1 | 13.3 | 37.1 | 493 | 23250 | 88.1 | 1106 | 39.01 | 74% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| APC E 7x5 | 1 | 7.5 | 28.2 | 211 | 12810 | 60.6 | 767 | 27.06 | 72% |
| APC E 7x5 | 1 | 10.1 | 42.6 | 430 | 15540 | 73.6 | 1158 | 40.85 | 65% |
| APC E 7x5 | 1 | 10.2 | 43.8 | 446 | 15690 | 74.3 | 1205 | 42.51 | 65% |
| APC E 7x5 | 1 | 10.5 | 46.4 | 487 | 16050 | 76.0 | 1256 | 44.30 | 65% |
