HXT - 35-42C
Specifications
- Type: Outrunner
Constants
- kV: 1028
- Rm: 0.081
- Io: 1.5
Io Test Data
Bruce Abbot test results
| Volts | Amps | RPM |
|---|---|---|
| 11.8 | 1.5 | 0 |
Test Data
Bruce Abbot test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS EP 8x4 | 1 | 11.5 | 9.4 | 108 | 10970 | 41.5 | 540 | 19.05 | 93% |
| APC E 10x7 | 1 | 10.8 | 26.3 | 284 | 8680 | 57.5 | 1170 | 41.27 | 78% |
| APC E 11x7 | 1 | 10.5 | 32.4 | 340 | 7928 | 52.5 | 1232 | 43.46 | 73% |
| APC E 11x8.5 | 1 | 10.4 | 34.7 | 360 | 7653 | 61.6 | 1290 | 45.50 | 72% |
| APC E 12x8 | 1 | 10.3 | 38.5 | 396 | 7251 | 54.9 | 1498 | 52.84 | 68% |
