Castle Creations - Mamba 2054
Specifications
- Type: Inrunner
Constants
- kV: 5440
- Rm: 0.112
- Io: 0.65
Io Test Data
Bruce Abbot test results
| Volts | Amps | RPM |
|---|---|---|
| 6 | 0.65 | 6050 |
| 8 | 0.7 | 0 |
Test Data
Bruce Abbot test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS EP 6x5 | 1 | 7.7 | 3 | 23 | 7351 | 34.8 | 139 | 4.90 | 18% |
| GWS EP 7x6 | 1 | 7.3 | 5.5 | 40 | 6676 | 37.9 | 264 | 9.31 | 17% |
| GWS EP 8x4.3 | 1 | 7.4 | 4.8 | 35 | 6880 | 28.0 | 295 | 10.41 | 17% |
| GWS EP 8x6 | 1 | 6 | 5.2 | 31 | 5530 | 31.4 | 265 | 9.35 | 17% |
| GWS EP 8x6 | 1 | 7.2 | 7 | 50 | 6377 | 36.2 | 358 | 12.63 | 16% |
| GWS EP 9x4.7 | 1 | 6 | 5.4 | 32 | 5469 | 24.3 | 309 | 10.90 | 17% |
| GWS EP 9x4.7 | 1 | 7.2 | 7.1 | 51 | 6321 | 28.1 | 419 | 14.78 | 16% |
| GWS EP 9x7 | 1 | 6 | 9.1 | 54 | 5030 | 33.3 | 384 | 13.55 | 15% |
| GWS EP 9x7 | 1 | 6.9 | 10.9 | 75 | 5600 | 37.1 | 462 | 16.30 | 15% |
| GWS EP 10x4.7 | 1 | 6 | 9.8 | 58 | 4965 | 22.1 | 483 | 17.04 | 15% |
| GWS EP 10x4.7 | 1 | 6.8 | 11.5 | 78 | 5448 | 24.2 | 590 | 20.81 | 15% |
| GWS EP 10x8 | 1 | 6 | 12.6 | 75 | 4602 | 34.9 | 500 | 17.64 | 14% |
| GWS EP 10x8 | 1 | 6.8 | 14.7 | 99 | 5009 | 38.0 | 584 | 20.60 | 14% |
| GWS EP 4 blade 10x8 | 1 | 6.7 | 16.4 | 109 | 4640 | 35.1 | 637 | 22.47 | 13% |
| GWS EP 11x4.7 | 1 | 6.9 | 13.9 | 95 | 5223 | 23.2 | 690 | 24.34 | 14% |
