MP Jet - 25/35/20 MkII
Specifications
- Type: Inrunner
Constants
- kV: 2764
- Rm: 0.11
- Io: 0.95
Io Test Data
Bruce Abbot test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.95 | 0 |
Test Data
Bruce Abbot test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS EP 4x2.5 | 1 | 7 | 4.4 | 30 | 17910 | 42.4 | 136 | 4.80 | 93% |
| APC E 5.5x4.5 | 1 | 7 | 15.2 | 106 | 14340 | 61.1 | 320 | 11.29 | 74% |
| APC E 6x4 | 1 | 7 | 15.8 | 110 | 14240 | 53.9 | 441 | 15.56 | 74% |
