Turnigy - 2836-2350
Specifications
- Type: Outrunner
- Weight: 81.00g (2.86oz)
- Maximum Amps: 30
Constants
- kV: 2800
- Rm: 0.08
- Io: 1.55
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.35 | 19410 |
| 8 | 1.4 | 21990 |
| 10 | 1.55 | 27630 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 4.1x4.1 | 1 | 6.9 | 7.25 | 50 | 17820 | 69.2 | 178 | 6.28 | 92% |
| APC E 4.1x4.1 | 1 | 7.8 | 9.05 | 70 | 20100 | 78.0 | 230 | 8.11 | 92% |
| APC E 4.1x4.1 | 1 | 8.8 | 11 | 96 | 22320 | 86.7 | 287 | 10.12 | 91% |
| APC E 4.1x4.1 | 1 | 9.8 | 13.15 | 128 | 24450 | 94.9 | 347 | 12.24 | 89% |
| APC E 4.1x4.1 | 1 | 10.7 | 15.45 | 165 | 26760 | 103.9 | 409 | 14.43 | 89% |
| EMP 4.1x4.1 | 1 | 13.3 | 27.2 | 361 | 30570 | 118.7 | 638 | 22.50 | 82% |
| APC E 4.5x4.1 | 1 | 6.8 | 9.25 | 62 | 17370 | 67.4 | 235 | 8.29 | 91% |
| APC E 4.5x4.1 | 1 | 7.8 | 11.5 | 89 | 19500 | 75.7 | 303 | 10.69 | 89% |
| APC E 4.5x4.1 | 1 | 8.8 | 14.05 | 123 | 21630 | 84.0 | 374 | 13.19 | 88% |
| APC E 4.5x4.1 | 1 | 9.7 | 16.6 | 161 | 23580 | 91.5 | 450 | 15.87 | 87% |
| APC E 4.5x4.1 | 1 | 10.7 | 19.6 | 209 | 25620 | 99.5 | 532 | 18.77 | 86% |
| APC E 4.7x4.25 | 1 | 6.9 | 10.95 | 75 | 17100 | 68.8 | 247 | 8.71 | 89% |
| APC E 4.7x4.25 | 1 | 7.8 | 13.6 | 106 | 19080 | 76.8 | 312 | 11.01 | 87% |
| APC E 4.7x4.25 | 1 | 8.7 | 16.2 | 140 | 21000 | 84.5 | 383 | 13.51 | 86% |
| APC E 4.7x4.25 | 1 | 9.7 | 19.4 | 188 | 22920 | 92.2 | 457 | 16.12 | 84% |
| APC E 4.7x4.25 | 1 | 10.6 | 22.8 | 241 | 24630 | 99.1 | 534 | 18.84 | 83% |
| EMP 5x5 | 1 | 7.6 | 17.8 | 135 | 17700 | 83.8 | 457 | 16.12 | 83% |
| EMP 5x5 | 1 | 11.2 | 32.4 | 362 | 23490 | 111.2 | 800 | 28.22 | 75% |
| Zagi Carbon 5.1x4.9 | 1 | 7.8 | 16.6 | 129 | 18210 | 84.5 | 452 | 15.94 | 83% |
| Zagi Carbon 5.1x4.9 | 1 | 11.2 | 30.1 | 337 | 24090 | 111.8 | 814 | 28.71 | 77% |
| APC E 5.25x6.25 | 1 | 7.6 | 23.8 | 180 | 15840 | 93.8 | 362 | 12.77 | 74% |
| APC E 5.25x6.25 | 1 | 10.5 | 37.2 | 390 | 20310 | 120.2 | 560 | 19.75 | 69% |
| APC E 5.5x4.5 | 1 | 7.4 | 19.5 | 144 | 16680 | 71.1 | 419 | 14.78 | 81% |
| APC E 5.5x4.5 | 1 | 9.2 | 22 | 202 | 18600 | 79.3 | 517 | 18.24 | 72% |
| APC E 5.5x4.5 | 1 | 10.9 | 34.1 | 371 | 22170 | 94.5 | 748 | 26.38 | 73% |
| APC E 5.5x4.5 | 1 | 11.2 | 36.7 | 411 | 22590 | 96.3 | 790 | 27.87 | 72% |
| APC E 6x4 | 1 | 7.6 | 20.6 | 156 | 16800 | 63.6 | 572 | 20.18 | 79% |
| APC E 6x4 | 1 | 10.3 | 32.9 | 338 | 20880 | 79.1 | 881 | 31.08 | 72% |
| APC E 6x4 | 1 | 10.5 | 33.6 | 352 | 21090 | 79.9 | 900 | 31.75 | 72% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| APC E 6x4 | 1 | 10.7 | 35.7 | 381 | 21450 | 81.2 | 952 | 33.58 | 72% |
