Turnigy - C2830-1050
Specifications
- Type: Outrunner
- Weight: 56.00g (1.98oz)
- Maximum Amps: 14
Constants
- kV: 1100
- Rm: 0.25
- Io: 0.9
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.75 | 7471 |
| 8 | 0.8 | 8557 |
| 10 | 0.9 | 10822 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 8x4 | 1 | 6.9 | 3.8 | 26 | 6720 | 25.4 | 238 | 8.40 | 89% |
| GWS HD 8x4 | 1 | 7.9 | 4.7 | 37 | 7590 | 28.8 | 305 | 10.76 | 87% |
| GWS HD 8x4 | 1 | 8.9 | 5.55 | 49 | 8340 | 31.6 | 371 | 13.09 | 85% |
| GWS HD 8x4 | 1 | 9.9 | 6.6 | 65 | 9120 | 34.5 | 448 | 15.80 | 84% |
| GWS HD 8x4 | 1 | 10.9 | 7.85 | 85 | 9930 | 37.6 | 538 | 18.98 | 83% |
| GWS HD 9x5 | 1 | 6.9 | 6.1 | 42 | 6150 | 29.1 | 361 | 12.73 | 81% |
| GWS HD 9x5 | 1 | 7.9 | 7.4 | 58 | 6840 | 32.4 | 453 | 15.98 | 79% |
| GWS HD 9x5 | 1 | 8.9 | 8.85 | 78 | 7500 | 35.5 | 552 | 19.47 | 77% |
| GWS HD 9x5 | 1 | 9.9 | 10.4 | 102 | 8160 | 38.6 | 660 | 23.28 | 75% |
| GWS HD 9x5 | 1 | 10.8 | 11.8 | 127 | 8700 | 41.2 | 746 | 26.31 | 73% |
| APC SF 10x4.7 | 1 | 6.8 | 9.5 | 64 | 5280 | 23.5 | 496 | 17.50 | 71% |
| APC SF 10x4.7 | 1 | 7.8 | 11.5 | 89 | 5790 | 25.8 | 603 | 21.27 | 67% |
| APC SF 10x4.7 | 1 | 8.8 | 13.4 | 117 | 6240 | 27.8 | 700 | 24.69 | 64% |
| APC SF 10x4.7 | 1 | 9.7 | 15.3 | 148 | 6630 | 29.5 | 786 | 27.73 | 62% |
| APC SF 10x4.7 | 1 | 10.7 | 17.2 | 184 | 6960 | 31.0 | 900 | 31.75 | 59% |
| GWS HD 10x6 | 1 | 6.9 | 8.05 | 55 | 5670 | 32.2 | 443 | 15.63 | 75% |
| GWS HD 10x6 | 1 | 7.8 | 9.75 | 76 | 6300 | 35.8 | 545 | 19.22 | 73% |
| GWS HD 10x6 | 1 | 8.8 | 11.3 | 99 | 6810 | 38.7 | 646 | 22.79 | 70% |
| GWS HD 10x6 | 1 | 9.8 | 13.1 | 128 | 7350 | 41.8 | 751 | 26.49 | 68% |
| GWS HD 10x6 | 1 | 10.7 | 14.7 | 157 | 7800 | 44.3 | 843 | 29.74 | 66% |
