Turnigy - SK3542-1000

Show Similiar


Specifications

  • Type: Outrunner
  • Weight: 142.00g (5.01oz)
  • Diameter: 35.00mm (1.38in)
  • Length: 42.00mm (1.65in)
  • Shaft Diameter: 4.00mm (0.16in)

Constants

  • kV: 1000
  • Rm: 0.048
  • Io: 1.7



Io Test Data

mark_q test results
Volts Amps RPM
11.72 2.93 11755
hudsontux test results
Volts Amps RPM
14.8 48 14800

Test Data

mark_q test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 10x5 1 14.75 38.45 567 14200 67.0 2211 77.99 96%
Zoar 11x5 1 11.08 27.06 299 10950 51.9 1559 54.99 99%
APC E 11x7 1 10.68 34.51 368 10050 66.6 1616 57.00 94%
APC E 12x6 1 10.4 35.58 370 9500 54.0 1843 65.01 91%
hudsontux test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 12x6 1 14 45 630 14300 71.0 2350 82.89 102%

Comments

mark_q on 2009-09-03 18:03:40
Please excuse the confusion as the values for thrust are not correct. The original values were in oz but were put in the "Thrust (g)" column. It should read:

APC E 10x5 2211g/78oz (4s)
Xoar 11x5 1559g/55oz
APC E 11x7 1616g/57oz
APC E 12x6 1843g/65oz

-Mark
