Pulso - X 2814/16

Show Similiar


Specifications

  • Type: Outrunner
  • Weight: 104.00g (3.67oz)
  • Diameter: 35.00mm (1.38in)
  • Length: 37.00mm (1.46in)
  • Shaft Diameter: 4.00mm (0.16in)
  • Maximum Amps: 30

Constants

  • kV: 1045
  • Rm: 0.122
  • Io: 1



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 0.95 7200
8 0.95 8250
10 1 10320

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 8x4 1 6.9 3.9 26 6840 25.9 242 8.54 95%
GWS HD 8x4 1 6.9 3.9 26 6840 25.9 242 8.54 95%
GWS HD 8x4 1 7.9 4.7 37 7800 29.6 316 11.15 94%
GWS HD 8x4 1 7.9 4.7 37 7800 29.6 316 11.15 94%
GWS HD 8x4 1 8.9 5.65 50 8610 32.6 389 13.72 93%
GWS HD 8x4 1 8.9 5.65 50 8610 32.6 389 13.72 93%
GWS HD 8x4 1 9.9 6.6 65 9480 35.9 465 16.40 92%
GWS HD 8x4 1 9.9 6.6 65 9480 35.9 465 16.40 92%
GWS HD 8x4 1 10.8 7.65 82 10320 39.1 559 19.72 91%
GWS HD 8x4 1 10.8 7.65 82 10320 39.1 559 19.72 91%
GWS HD 9x5 1 6.9 6.6 45 6480 30.7 405 14.29 90%
GWS HD 9x5 1 6.9 6.6 45 6480 30.7 405 14.29 90%
GWS HD 9x5 1 7.8 8.1 63 7320 34.7 508 17.92 90%
GWS HD 9x5 1 7.8 8.1 63 7320 34.7 508 17.92 90%
GWS HD 9x5 1 8.8 9.9 87 8100 38.4 634 22.36 88%
GWS HD 9x5 1 8.8 9.9 87 8100 38.4 634 22.36 88%
GWS HD 9x5 1 9.7 11.55 112 8790 41.6 760 26.81 87%
GWS HD 9x5 1 9.7 11.55 112 8790 41.6 760 26.81 87%
GWS HD 9x5 1 10.7 13.4 143 9510 45.0 900 31.75 85%
GWS HD 9x5 1 10.7 13.4 143 9510 45.0 900 31.75 85%
GWS HD 10x6 1 6.8 8.9 60 6210 35.3 510 17.99 87%
GWS HD 10x6 1 6.8 8.9 60 6210 35.3 510 17.99 87%
GWS HD 10x6 1 7.8 10.9 85 6960 39.5 640 22.58 85%
GWS HD 10x6 1 7.8 10.9 85 6960 39.5 640 22.58 85%
GWS HD 10x6 1 8.7 13 113 7650 43.5 772 27.23 84%
GWS HD 10x6 1 8.7 13 113 7650 43.5 772 27.23 84%
GWS HD 10x6 1 9.7 15.35 148 8340 47.4 930 32.80 82%
GWS HD 10x6 1 9.7 15.35 148 8340 47.4 930 32.80 82%
GWS HD 10x6 1 10.7 17.45 186 8940 50.8 1060 37.39 80%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 10x6 1 10.7 17.45 186 8940 50.8 1060 37.39 80%
GWS HD 10x8 1 6.8 14.2 96 5610 42.5 548 19.33 79%
GWS HD 10x8 1 6.8 14.2 96 5610 42.5 548 19.33 79%
GWS HD 10x8 1 7.7 16.9 130 6210 47.0 658 23.21 77%
GWS HD 10x8 1 7.7 16.9 130 6210 47.0 658 23.21 77%
GWS HD 10x8 1 8.6 20 172 6720 50.9 779 27.48 75%
GWS HD 10x8 1 8.6 20 172 6720 50.9 779 27.48 75%
GWS HD 10x8 1 11.2 29.1 325 8010 60.7 1111 39.19 68%
GWS HD 10x8 1 11.2 29.1 325 8010 60.7 1111 39.19 68%
GWS HD 11x7 1 6.8 13.2 89 5700 37.8 709 25.01 80%
GWS HD 11x7 1 6.8 13.2 89 5700 37.8 709 25.01 80%
GWS HD 11x7 1 7.7 16.1 123 6330 42.0 875 30.86 79%
GWS HD 11x7 1 7.7 16.1 123 6330 42.0 875 30.86 79%
GWS HD 11x7 1 8.7 18.9 164 6900 45.7 1031 36.37 76%
GWS HD 11x7 1 8.7 18.9 164 6900 45.7 1031 36.37 76%
GWS HD 11x7 1 9.6 21.8 209 7410 49.1 1190 41.98 74%
GWS HD 11x7 1 9.6 21.8 209 7410 49.1 1190 41.98 74%
GWS HD 11x7 1 10.6 24.8 262 7920 52.5 1350 47.62 71%
GWS HD 11x7 1 10.6 24.8 262 7920 52.5 1350 47.62 71%
GWS HD 11x7 1 11 25.7 282 8010 53.1 1410 49.74 70%
GWS HD 11x7 1 11 25.7 282 8010 53.1 1410 49.74 70%
GWS HD 11x7 1 11.2 27.2 304 8160 54.1 1485 52.38 70%
GWS HD 11x7 1 11.2 27.2 304 8160 54.1 1485 52.38 70%
