KEDA - TR2837/10

Show Similiar


Specifications

  • Type: Outrunner
  • Weight: 81.00g (2.86oz)
  • Diameter: 28.00mm (1.10in)
  • Length: 37.00mm (1.46in)
  • Shaft Diameter: 3.17mm (0.12in)
  • Maximum Amps: 30

Constants

  • kV: 1500
  • Rm: 0.1
  • Io: 1.65



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 1.35 10382
8 1.4 11773
10 1.65 14820

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
APC E 7x5 1 6.8 8.7 59 8850 41.9 347 12.24 87%
APC E 7x5 1 7.8 10.9 85 9960 47.2 444 15.66 85%
APC E 7x5 1 8.7 13 113 10980 52.0 542 19.12 84%
APC E 7x5 1 9.6 15.1 144 12000 56.8 667 23.53 83%
APC E 7x5 1 10.6 17.8 188 13200 62.5 784 27.65 83%
APC Sport 7x7 1 6.8 9.4 63 8730 57.9 328 11.57 86%
APC Sport 7x7 1 7.7 11.8 90 9810 65.0 418 14.74 85%
APC Sport 7x7 1 8.7 14 121 10860 72.0 509 17.95 83%
APC Sport 7x7 1 9.6 16.4 157 11790 78.2 603 21.27 82%
APC Sport 7x7 1 10.6 19.2 203 12750 84.5 704 24.83 80%
GWS HD 8x4 1 6.8 8.3 56 8880 33.6 417 14.71 87%
GWS HD 8x4 1 7.7 10.5 80 10050 38.1 540 19.05 87%
GWS HD 8x4 1 8.7 12.85 111 11100 42.0 673 23.74 85%
GWS HD 8x4 1 9.6 15.1 144 12030 45.6 798 28.15 84%
GWS HD 8x4 1 10.6 17.7 187 12960 49.1 936 33.02 82%
GWS HD 9x5 1 6.7 13.75 92 8010 37.9 635 22.40 80%
GWS HD 9x5 1 7.6 16.7 126 8820 41.8 782 27.58 77%
GWS HD 9x5 1 7.6 16.7 126 8820 41.8 782 27.58 77%
GWS HD 9x5 1 8.6 20.4 175 9750 46.2 961 33.90 76%
GWS HD 9x5 1 9.8 23.4 229 10500 49.7 1125 39.68 71%
GWS HD 9x5 1 10.8 25.6 276 10950 51.9 1240 43.74 68%
GWS HD 9x5 1 11.3 31.2 352 11700 55.4 1452 51.22 69%
