KEDA - TR2837/08
Specifications
- Type: Outrunner
- Weight: 80.00g (2.82oz)
- Diameter: 28.00mm (1.10in)
- Length: 37.00mm (1.46in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 30
Constants
- kV: 1860
- Rm: 0.09
- Io: 2.35
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.85 | 12700 |
| 8 | 2.05 | 14670 |
| 10 | 2.35 | 18200 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| Zagi Carbon 5.1x4.9 | 1 | 6.9 | 6.4 | 44 | 11850 | 55.0 | 201 | 7.09 | 92% |
| Zagi Carbon 5.1x4.9 | 1 | 7.8 | 7.8 | 60 | 13260 | 61.5 | 250 | 8.82 | 91% |
| Zagi Carbon 5.1x4.9 | 1 | 8.8 | 9.5 | 83 | 14910 | 69.2 | 320 | 11.29 | 91% |
| Zagi Carbon 5.1x4.9 | 1 | 9.7 | 11.15 | 108 | 16290 | 75.6 | 383 | 13.51 | 90% |
| Zagi Carbon 5.1x4.9 | 1 | 10.8 | 12.85 | 138 | 17760 | 82.4 | 455 | 16.05 | 88% |
| Zagi Carbon 5.1x4.9 | 1 | 14.3 | 20.8 | 297 | 22560 | 104.7 | 745 | 26.28 | 85% |
| APC E 6x4 | 1 | 6.9 | 7.8 | 53 | 11580 | 43.9 | 260 | 9.17 | 90% |
| APC E 6x4 | 1 | 7.8 | 9.5 | 74 | 12960 | 49.1 | 331 | 11.68 | 89% |
| APC E 6x4 | 1 | 8.8 | 11.65 | 102 | 14460 | 54.8 | 426 | 15.03 | 88% |
| APC E 6x4 | 1 | 9.7 | 13.9 | 134 | 15840 | 60.0 | 514 | 18.13 | 88% |
| APC E 6x4 | 1 | 10.7 | 16.8 | 179 | 17070 | 64.7 | 596 | 21.02 | 86% |
| EMP 6x4 | 1 | 6.8 | 8.45 | 57 | 11400 | 43.2 | 323 | 11.39 | 90% |
| EMP 6x4 | 1 | 7.8 | 10.3 | 80 | 12840 | 48.6 | 409 | 14.43 | 89% |
| EMP 6x4 | 1 | 8.7 | 12.2 | 106 | 14160 | 53.6 | 494 | 17.43 | 88% |
| EMP 6x4 | 1 | 9.7 | 14.75 | 143 | 15540 | 58.9 | 602 | 21.23 | 86% |
| EMP 6x4 | 1 | 10.7 | 17.05 | 182 | 16830 | 63.8 | 706 | 24.90 | 85% |
| EMP 6x5 | 1 | 6.9 | 7.3 | 50 | 11700 | 55.4 | 265 | 9.35 | 91% |
| EMP 6x5 | 1 | 7.8 | 8.85 | 69 | 13080 | 61.9 | 346 | 12.20 | 90% |
| EMP 6x5 | 1 | 8.8 | 10.85 | 95 | 14640 | 69.3 | 449 | 15.84 | 89% |
| EMP 6x5 | 1 | 9.8 | 12.75 | 124 | 16050 | 76.0 | 556 | 19.61 | 88% |
| EMP 6x5 | 1 | 10.7 | 14.65 | 156 | 17370 | 82.2 | 645 | 22.75 | 87% |
| APC E 6x5.5 | 1 | 6.8 | 10.6 | 72 | 11040 | 57.5 | 275 | 9.70 | 87% |
| APC E 6x5.5 | 1 | 7.8 | 12.7 | 99 | 12360 | 64.4 | 348 | 12.28 | 85% |
| APC E 6x5.5 | 1 | 8.8 | 14.9 | 131 | 13770 | 71.7 | 441 | 15.56 | 84% |
| APC E 6x5.5 | 1 | 9.7 | 17.7 | 171 | 15120 | 78.8 | 539 | 19.01 | 84% |
| APC E 6x5.5 | 1 | 10.7 | 20.1 | 215 | 16260 | 84.7 | 617 | 21.76 | 82% |
| APC E 7x5 | 1 | 7.7 | 17.5 | 134 | 11400 | 54.0 | 603 | 21.27 | 80% |
| APC E 7x5 | 1 | 11.3 | 31.6 | 357 | 15210 | 72.0 | 1142 | 40.28 | 72% |
| APC Sport 7x6 | 1 | 7.7 | 17.05 | 131 | 11340 | 64.4 | 509 | 17.95 | 79% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| APC Sport 7x6 | 1 | 11.1 | 31.4 | 348 | 14940 | 84.9 | 935 | 32.98 | 72% |
