KEDA - TR2837/18
Specifications
- Type: Outrunner
- Weight: 81.00g (2.86oz)
- Diameter: 28.00mm (1.10in)
- Length: 37.00mm (1.46in)
- Shaft Diameter: 3.17mm (0.12in)
- Maximum Amps: 20
Constants
- kV: 865
- Rm: 0.22
- Io: 0.65
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.55 | 5970 |
| 8 | 0.55 | 6810 |
| 10 | 0.65 | 8520 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 9x5 | 1 | 6.9 | 3.8 | 26 | 5400 | 25.6 | 280 | 9.88 | 90% |
| GWS HD 9x5 | 1 | 7.9 | 4.65 | 36 | 6030 | 28.6 | 352 | 12.42 | 88% |
| GWS HD 9x5 | 1 | 8.9 | 5.7 | 50 | 6750 | 32.0 | 442 | 15.59 | 88% |
| GWS HD 9x5 | 1 | 9.8 | 6.5 | 63 | 7320 | 34.7 | 521 | 18.38 | 86% |
| GWS HD 9x5 | 1 | 10.8 | 7.6 | 82 | 7920 | 37.5 | 619 | 21.83 | 85% |
| GWS HD 9x5 | 1 | 14 | 11.1 | 155 | 9660 | 45.7 | 934 | 32.95 | 80% |
| GWS HD 9x5 | 1 | 14.5 | 11.8 | 171 | 9930 | 47.0 | 985 | 34.74 | 79% |
| GWS HD 10x6 | 1 | 6.9 | 5.25 | 36 | 5130 | 29.1 | 365 | 12.87 | 86% |
| GWS HD 10x6 | 1 | 7.9 | 6.4 | 50 | 5730 | 32.6 | 458 | 16.16 | 84% |
| GWS HD 10x6 | 1 | 8.8 | 7.6 | 66 | 6300 | 35.8 | 556 | 19.61 | 83% |
| GWS HD 10x6 | 1 | 9.8 | 9 | 88 | 6870 | 39.0 | 662 | 23.35 | 81% |
| GWS HD 10x6 | 1 | 10.8 | 10.3 | 111 | 7380 | 41.9 | 766 | 27.02 | 79% |
| GWS HD 3T 10x6 | 1 | 6.9 | 6.6 | 45 | 4900 | 27.8 | 424 | 14.96 | 82% |
| GWS HD 3T 10x6 | 1 | 7.8 | 8 | 62 | 5420 | 30.8 | 530 | 18.70 | 80% |
| GWS HD 3T 10x6 | 1 | 8.8 | 9.55 | 84 | 5980 | 34.0 | 647 | 22.82 | 79% |
| GWS HD 3T 10x6 | 1 | 9.8 | 11 | 107 | 6460 | 36.7 | 755 | 26.63 | 76% |
| GWS HD 3T 10x6 | 1 | 10.7 | 12.5 | 133 | 6920 | 39.3 | 878 | 30.97 | 75% |
| GWS HD 3T 10x6 | 1 | 14 | 17.8 | 249 | 8320 | 47.3 | 1258 | 44.37 | 69% |
| GWS HD 11x7 | 1 | 6.9 | 7.5 | 51 | 4740 | 31.4 | 495 | 17.46 | 79% |
| GWS HD 11x7 | 1 | 7.8 | 9 | 70 | 5220 | 34.6 | 608 | 21.45 | 77% |
| GWS HD 11x7 | 1 | 8.8 | 10.75 | 94 | 5760 | 38.2 | 720 | 25.40 | 76% |
| GWS HD 11x7 | 1 | 9.7 | 12.3 | 119 | 6180 | 41.0 | 825 | 29.10 | 74% |
| GWS HD 11x7 | 1 | 10.7 | 13.85 | 148 | 6600 | 43.8 | 950 | 33.51 | 71% |
| GWS HD 12x8 | 1 | 6.8 | 10 | 68 | 4320 | 32.7 | 593 | 20.92 | 73% |
| GWS HD 12x8 | 1 | 7.8 | 11.9 | 92 | 4740 | 35.9 | 713 | 25.15 | 70% |
| GWS HD 12x8 | 1 | 8.7 | 13.9 | 120 | 5130 | 38.9 | 836 | 29.49 | 68% |
| GWS HD 12x8 | 1 | 9.7 | 16 | 155 | 5490 | 41.6 | 968 | 34.15 | 65% |
| GWS HD 12x8 | 1 | 10.7 | 18 | 192 | 5790 | 43.9 | 1080 | 38.10 | 63% |
