Motrolfly - 2203-1350 v2
Specifications
- Type: Outrunner
- Weight: 18.00g (0.63oz)
- Diameter: 28.00mm (1.10in)
- Length: 13.70mm (0.54in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 5
Constants
- kV: 1315
- Rm: 1.03
- Io: 0.3
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.25 | 8850 |
| 8 | 0.25 | 10320 |
| 10 | 0.3 | 12810 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 6x3 | 1 | 7 | 1.4 | 9 | 7560 | 21.5 | 88 | 3.10 | 82% |
| GWS HD 6x3 | 1 | 7 | 1.4 | 9 | 7560 | 21.5 | 88 | 3.10 | 82% |
| GWS HD 6x3 | 1 | 7.9 | 1.65 | 13 | 8460 | 24.0 | 113 | 3.99 | 81% |
| GWS HD 6x3 | 1 | 7.9 | 1.65 | 13 | 8460 | 24.0 | 113 | 3.99 | 81% |
| GWS HD 6x3 | 1 | 8.9 | 2 | 17 | 9390 | 26.7 | 140 | 4.94 | 80% |
| GWS HD 6x3 | 1 | 8.9 | 2 | 17 | 9390 | 26.7 | 140 | 4.94 | 80% |
| GWS HD 6x3 | 1 | 9.9 | 2.3 | 22 | 10200 | 29.0 | 167 | 5.89 | 78% |
| GWS HD 6x3 | 1 | 9.9 | 2.3 | 22 | 10200 | 29.0 | 167 | 5.89 | 78% |
| GWS HD 6x3 | 1 | 10.9 | 2.6 | 28 | 10980 | 31.2 | 195 | 6.88 | 77% |
| GWS HD 6x3 | 1 | 10.9 | 2.6 | 28 | 10980 | 31.2 | 195 | 6.88 | 77% |
| GWS RS 6x5 | 1 | 6.9 | 2.4 | 16 | 6330 | 30.0 | 108 | 3.81 | 70% |
| GWS RS 6x5 | 1 | 6.9 | 2.4 | 16 | 6330 | 30.0 | 108 | 3.81 | 70% |
| GWS RS 6x5 | 1 | 7.4 | 2.6 | 19 | 6600 | 31.2 | 117 | 4.13 | 68% |
| GWS RS 6x5 | 1 | 7.4 | 2.6 | 19 | 6600 | 31.2 | 117 | 4.13 | 68% |
| GWS RS 6x5 | 1 | 7.9 | 2.8 | 22 | 6900 | 32.7 | 131 | 4.62 | 66% |
| GWS RS 6x5 | 1 | 7.9 | 2.8 | 22 | 6900 | 32.7 | 131 | 4.62 | 66% |
| GWS RS 6x5 | 1 | 8.9 | 3.3 | 29 | 7440 | 35.2 | 153 | 5.40 | 64% |
| GWS RS 6x5 | 1 | 8.9 | 3.3 | 29 | 7440 | 35.2 | 153 | 5.40 | 64% |
| GWS RS 6x5 | 1 | 9.9 | 3.75 | 37 | 7950 | 37.6 | 175 | 6.17 | 61% |
| GWS RS 6x5 | 1 | 9.9 | 3.75 | 37 | 7950 | 37.6 | 175 | 6.17 | 61% |
| GWS RS 6x5 | 1 | 10.9 | 4.15 | 45 | 8400 | 39.8 | 195 | 6.88 | 59% |
| GWS RS 6x5 | 1 | 10.9 | 4.15 | 45 | 8400 | 39.8 | 195 | 6.88 | 59% |
| GWS HD 7x3.5 | 1 | 6.9 | 1.8 | 12 | 7050 | 23.4 | 109 | 3.84 | 78% |
| GWS HD 7x3.5 | 1 | 6.9 | 1.8 | 12 | 7050 | 23.4 | 109 | 3.84 | 78% |
| GWS HD 7x3.5 | 1 | 7.9 | 2.15 | 16 | 7830 | 25.9 | 140 | 4.94 | 75% |
| GWS HD 7x3.5 | 1 | 7.9 | 2.15 | 16 | 7830 | 25.9 | 140 | 4.94 | 75% |
| GWS HD 7x3.5 | 1 | 8.9 | 2.5 | 22 | 8580 | 28.4 | 171 | 6.03 | 73% |
| GWS HD 7x3.5 | 1 | 8.9 | 2.5 | 22 | 8580 | 28.4 | 171 | 6.03 | 73% |
| GWS HD 7x3.5 | 1 | 9.9 | 2.95 | 29 | 9360 | 31.0 | 206 | 7.27 | 72% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 7x3.5 | 1 | 9.9 | 2.95 | 29 | 9360 | 31.0 | 206 | 7.27 | 72% |
| GWS HD 7x3.5 | 1 | 10.9 | 3.3 | 35 | 9930 | 32.9 | 230 | 8.11 | 69% |
| GWS HD 7x3.5 | 1 | 10.9 | 3.3 | 35 | 9930 | 32.9 | 230 | 8.11 | 69% |
| GWS RS 7x6 | 1 | 6.9 | 3.4 | 23 | 5100 | 29.0 | 152 | 5.36 | 56% |
| GWS RS 7x6 | 1 | 6.9 | 3.4 | 23 | 5100 | 29.0 | 152 | 5.36 | 56% |
| GWS RS 7x6 | 1 | 7.4 | 3.6 | 26 | 5310 | 30.2 | 162 | 5.71 | 55% |
| GWS RS 7x6 | 1 | 7.4 | 3.6 | 26 | 5310 | 30.2 | 162 | 5.71 | 55% |
| GWS RS 7x6 | 1 | 7.9 | 3.85 | 30 | 5490 | 31.2 | 174 | 6.14 | 53% |
| GWS RS 7x6 | 1 | 7.9 | 3.85 | 30 | 5490 | 31.2 | 174 | 6.14 | 53% |
| GWS RS 7x6 | 1 | 8.9 | 4.3 | 38 | 5820 | 33.1 | 195 | 6.88 | 50% |
| GWS RS 7x6 | 1 | 8.9 | 4.3 | 38 | 5820 | 33.1 | 195 | 6.88 | 50% |
| GWS RS 7x6 | 1 | 9.9 | 4.75 | 47 | 6120 | 34.8 | 222 | 7.83 | 47% |
| GWS RS 7x6 | 1 | 9.9 | 4.75 | 47 | 6120 | 34.8 | 222 | 7.83 | 47% |
| GWS RS 7x6 | 1 | 10.8 | 5.2 | 56 | 6390 | 36.3 | 240 | 8.47 | 45% |
| GWS RS 7x6 | 1 | 10.8 | 5.2 | 56 | 6390 | 36.3 | 240 | 8.47 | 45% |
| GWS HD 8x4 | 1 | 6.9 | 2.9 | 20 | 5700 | 21.6 | 170 | 6.00 | 63% |
| GWS HD 8x4 | 1 | 6.9 | 2.9 | 20 | 5700 | 21.6 | 170 | 6.00 | 63% |
| GWS HD 8x4 | 1 | 7.4 | 3.05 | 22 | 5940 | 22.5 | 183 | 6.46 | 61% |
| GWS HD 8x4 | 1 | 7.4 | 3.05 | 22 | 5940 | 22.5 | 183 | 6.46 | 61% |
| GWS HD 8x4 | 1 | 7.9 | 3.3 | 26 | 6210 | 23.5 | 203 | 7.16 | 60% |
| GWS HD 8x4 | 1 | 7.9 | 3.3 | 26 | 6210 | 23.5 | 203 | 7.16 | 60% |
| GWS HD 8x4 | 1 | 8.9 | 3.8 | 33 | 6720 | 25.4 | 237 | 8.36 | 57% |
| GWS HD 8x4 | 1 | 8.9 | 3.8 | 33 | 6720 | 25.4 | 237 | 8.36 | 57% |
| GWS HD 8x4 | 1 | 9.9 | 4.3 | 42 | 7110 | 26.9 | 271 | 9.56 | 55% |
| GWS HD 8x4 | 1 | 9.9 | 4.3 | 42 | 7110 | 26.9 | 271 | 9.56 | 55% |
| GWS HD 8x4 | 1 | 10.8 | 4.7 | 50 | 7440 | 28.2 | 296 | 10.44 | 52% |
| GWS HD 8x4 | 1 | 10.8 | 4.7 | 50 | 7440 | 28.2 | 296 | 10.44 | 52% |
| GWS RS 8x4.3 | 1 | 6.9 | 3.35 | 23 | 5100 | 20.8 | 178 | 6.28 | 56% |
| GWS RS 8x4.3 | 1 | 6.9 | 3.35 | 23 | 5100 | 20.8 | 178 | 6.28 | 56% |
| GWS RS 8x4.3 | 1 | 7.4 | 3.55 | 26 | 5280 | 21.5 | 189 | 6.67 | 54% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS RS 8x4.3 | 1 | 7.4 | 3.55 | 26 | 5280 | 21.5 | 189 | 6.67 | 54% |
| GWS HD 9x5 | 1 | 6.9 | 3.8 | 26 | 4380 | 20.7 | 190 | 6.70 | 48% |
| GWS HD 9x5 | 1 | 6.9 | 3.8 | 26 | 4380 | 20.7 | 190 | 6.70 | 48% |
| GWS HD 9x5 | 1 | 7.4 | 4 | 29 | 4530 | 21.4 | 201 | 7.09 | 47% |
| GWS HD 9x5 | 1 | 7.4 | 4 | 29 | 4530 | 21.4 | 201 | 7.09 | 47% |
