KEDA - KD2213/1920
Specifications
- Type: Outrunner
- Weight: 57.00g (2.01oz)
- Diameter: 27.60mm (1.09in)
- Length: 32.60mm (1.28in)
- Shaft Diameter: 3.20mm (0.13in)
- Maximum Amps: 20
Constants
- kV: 2050
- Rm: 0.15
- Io: 1.75
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.5 | 13890 |
| 8 | 1.6 | 16000 |
| 10 | 1.75 | 20030 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| Zagi Carbon 5.1x4.9 | 1 | 6.9 | 7.1 | 48 | 12300 | 57.1 | 219 | 7.72 | 87% |
| Zagi Carbon 5.1x4.9 | 1 | 7.8 | 8.7 | 67 | 13770 | 63.9 | 276 | 9.74 | 86% |
| Zagi Carbon 5.1x4.9 | 1 | 8.8 | 10.4 | 91 | 15210 | 70.6 | 336 | 11.85 | 84% |
| Zagi Carbon 5.1x4.9 | 1 | 9.8 | 12.5 | 122 | 16470 | 76.4 | 402 | 14.18 | 82% |
| Zagi Carbon 5.1x4.9 | 1 | 10.7 | 14.5 | 155 | 18030 | 83.7 | 479 | 16.90 | 82% |
| Graupner CAM 5.2x5.2 | 1 | 6.9 | 8.1 | 55 | 11850 | 58.4 | 199 | 7.02 | 84% |
| Graupner CAM 5.2x5.2 | 1 | 7.8 | 9.9 | 77 | 13260 | 65.3 | 250 | 8.82 | 83% |
| Graupner CAM 5.2x5.2 | 1 | 8.8 | 12.05 | 106 | 14640 | 72.1 | 305 | 10.76 | 81% |
| Graupner CAM 5.2x5.2 | 1 | 9.8 | 14.3 | 140 | 15990 | 78.7 | 363 | 12.80 | 80% |
| Graupner CAM 5.2x5.2 | 1 | 10.8 | 16.65 | 179 | 17160 | 84.5 | 423 | 14.92 | 78% |
| EMP 6x4 | 1 | 6.9 | 6.85 | 47 | 11370 | 43.1 | 243 | 8.57 | 80% |
| EMP 6x4 | 1 | 7.8 | 8.45 | 65 | 12870 | 48.8 | 324 | 11.43 | 80% |
| EMP 6x4 | 1 | 8.8 | 10.5 | 92 | 14370 | 54.4 | 415 | 14.64 | 80% |
| EMP 6x4 | 1 | 9.8 | 12.75 | 124 | 16020 | 60.7 | 530 | 18.70 | 80% |
| EMP 6x4 | 1 | 10.8 | 14.8 | 159 | 17490 | 66.2 | 650 | 22.93 | 79% |
| Aeronaut 6x5 | 1 | 6.9 | 8.6 | 59 | 10740 | 50.9 | 260 | 9.17 | 76% |
| Aeronaut 6x5 | 1 | 7.8 | 10.5 | 81 | 11940 | 56.5 | 319 | 11.25 | 75% |
| Aeronaut 6x5 | 1 | 8.8 | 12.3 | 108 | 13770 | 65.2 | 420 | 14.82 | 76% |
| Aeronaut 6x5 | 1 | 9.7 | 17.3 | 167 | 15390 | 72.9 | 530 | 18.70 | 77% |
| Aeronaut 6x5 | 1 | 10.7 | 20.3 | 217 | 16750 | 79.3 | 640 | 22.58 | 76% |
| EMP 6x5 | 1 | 6.9 | 8.4 | 57 | 10950 | 51.9 | 300 | 10.58 | 77% |
| EMP 6x5 | 1 | 7.8 | 10.45 | 81 | 12390 | 58.7 | 367 | 12.95 | 77% |
| EMP 6x5 | 1 | 8.8 | 12 | 105 | 13740 | 65.1 | 458 | 16.16 | 76% |
| EMP 6x5 | 1 | 9.7 | 14.5 | 140 | 14910 | 70.6 | 540 | 19.05 | 75% |
| EMP 6x5 | 1 | 10.7 | 17.8 | 190 | 16440 | 77.8 | 666 | 23.49 | 75% |
| APC E 7x5 | 1 | 6.9 | 13.3 | 91 | 9360 | 44.3 | 397 | 14.00 | 66% |
| APC E 7x5 | 1 | 7.7 | 16.8 | 129 | 10590 | 50.1 | 502 | 17.71 | 67% |
| APC E 7x5 | 1 | 8.6 | 19.4 | 166 | 11760 | 55.7 | 620 | 21.87 | 67% |
| APC E 7x5 | 1 | 10.6 | 26 | 275 | 13050 | 61.8 | 820 | 28.92 | 60% |
