Infinite - A1705
Specifications
- Type: Outrunner
- Weight: 18.00g (0.63oz)
- Diameter: 21.00mm (0.83in)
- Length: 22.00mm (0.87in)
- Shaft Diameter: 2.00mm (0.08in)
- Maximum Amps: 8
Constants
- kV: 2340
- Rm: 0.32
- Io: 0.85
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.6 | 15890 |
| 8 | 0.65 | 18200 |
| 10 | 0.85 | 22705 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 4x4 | 1 | 6.9 | 3.75 | 25 | 13440 | 50.9 | 103 | 3.63 | 83% |
| GWS HD 4x4 | 1 | 7.9 | 4.55 | 35 | 14910 | 56.5 | 127 | 4.48 | 81% |
| GWS HD 4x4 | 1 | 8.9 | 5.4 | 48 | 16380 | 62.0 | 154 | 5.43 | 79% |
| GWS HD 4x4 | 1 | 9.9 | 6.35 | 62 | 17700 | 67.0 | 182 | 6.42 | 76% |
| GWS HD 4x4 | 1 | 10.8 | 7.25 | 78 | 18990 | 71.9 | 207 | 7.30 | 75% |
| Gunther White 4.92x4.33 | 1 | 7 | 6.15 | 43 | 11700 | 48.0 | 199 | 7.02 | 71% |
| Gunther White 4.92x4.33 | 1 | 7.4 | 6.65 | 49 | 12210 | 50.1 | 218 | 7.69 | 71% |
| GWS HD 5x3 | 1 | 7 | 3.75 | 26 | 13620 | 38.7 | 162 | 5.71 | 83% |
| GWS HD 5x3 | 1 | 7.4 | 4.05 | 29 | 14160 | 40.2 | 177 | 6.24 | 82% |
| GWS HD 6x3 | 1 | 7 | 5.65 | 39 | 12180 | 34.6 | 236 | 8.32 | 74% |
| GWS HD 6x3 | 1 | 7.4 | 6.05 | 44 | 12600 | 35.8 | 255 | 8.99 | 73% |
| GWS HD 7x3.5 | 1 | 7 | 6.9 | 48 | 10770 | 35.7 | 275 | 9.70 | 66% |
| GWS HD 7x3.5 | 1 | 7.4 | 7.55 | 55 | 11250 | 37.3 | 296 | 10.44 | 65% |
| APC SF 7x4 | 1 | 7 | 9.75 | 68 | 8850 | 33.5 | 313 | 11.04 | 54% |
| APC SF 7x4 | 1 | 7.4 | 10.1 | 74 | 8970 | 34.0 | 327 | 11.53 | 52% |
Comments
Dr Kiwi on 2010-12-22 11:08:33
Built-in propsaver, no exposed shaft
