TheWorldModels - KM 0203800
Specifications
- Type: Outrunner
- Weight: 49.00g (1.73oz)
- Diameter: 28.00mm (1.10in)
- Length: 26.00mm (1.02in)
- Shaft Diameter: 2.30mm (0.09in)
- Maximum Amps: 20
Constants
- kV: 2230
- Rm: 0.113
- Io: 1.15
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.05 | 15180 |
| 8 | 1.1 | 17400 |
| 10 | 1.15 | 21680 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| Graupner 3x3 | 1 | 6.9 | 2.3 | 15 | 14850 | 42.2 | 55 | 1.94 | 97% |
| Graupner 3x3 | 1 | 7.9 | 2.8 | 22 | 16860 | 47.9 | 72 | 2.54 | 96% |
| Graupner 3x3 | 1 | 8.9 | 3.25 | 28 | 18870 | 53.6 | 90 | 3.17 | 95% |
| Graupner 3x3 | 1 | 9.9 | 3.8 | 37 | 21060 | 59.8 | 112 | 3.95 | 95% |
| Graupner 3x3 | 1 | 10.9 | 4.5 | 49 | 23130 | 65.7 | 134 | 4.73 | 95% |
| EMP 4.1x4.1 | 1 | 6.9 | 4.95 | 34 | 14130 | 54.9 | 132 | 4.66 | 92% |
| EMP 4.1x4.1 | 1 | 7.9 | 6.15 | 48 | 15960 | 62.0 | 170 | 6.00 | 91% |
| EMP 4.1x4.1 | 1 | 8.8 | 7.4 | 65 | 17730 | 68.8 | 209 | 7.37 | 90% |
| EMP 4.1x4.1 | 1 | 9.8 | 8.85 | 86 | 19530 | 75.8 | 254 | 8.96 | 89% |
| EMP 4.1x4.1 | 1 | 10.8 | 10.3 | 111 | 21120 | 82.0 | 300 | 10.58 | 88% |
| EMP 4.75x4.75 | 1 | 6.8 | 6.9 | 46 | 13500 | 60.7 | 195 | 6.88 | 89% |
| EMP 4.75x4.75 | 1 | 7.8 | 8.4 | 65 | 15150 | 68.1 | 247 | 8.71 | 87% |
| EMP 4.75x4.75 | 1 | 8.8 | 10.25 | 90 | 16920 | 76.1 | 305 | 10.76 | 86% |
| EMP 4.75x4.75 | 1 | 9.7 | 12 | 116 | 18360 | 82.6 | 358 | 12.63 | 85% |
| EMP 4.75x4.75 | 1 | 10.7 | 14.3 | 153 | 19800 | 89.1 | 429 | 15.13 | 83% |
| GWS HD 9x5 | 2.286 | 6.8 | 6.1 | 41 | 6000 | 28.4 | 348 | 12.28 | 90% |
| GWS HD 9x5 | 2.286 | 7.8 | 7.45 | 58 | 6810 | 32.2 | 451 | 15.91 | 90% |
| GWS HD 9x5 | 2.286 | 8.8 | 9.1 | 80 | 7560 | 35.8 | 562 | 19.82 | 88% |
| GWS HD 9x5 | 2.286 | 9.8 | 10.7 | 104 | 8280 | 39.2 | 678 | 23.92 | 87% |
| GWS HD 9x5 | 2.286 | 10.7 | 12.45 | 133 | 8940 | 42.3 | 796 | 28.08 | 86% |
| GWS HD 10x6 | 2.286 | 6.8 | 8.05 | 54 | 5790 | 32.9 | 450 | 15.87 | 87% |
| GWS HD 10x6 | 2.286 | 7.8 | 9.9 | 77 | 6510 | 37.0 | 571 | 20.14 | 86% |
| GWS HD 10x6 | 2.286 | 8.8 | 11.85 | 104 | 7140 | 40.6 | 676 | 23.85 | 83% |
| GWS HD 10x6 | 2.286 | 9.7 | 13.9 | 134 | 7800 | 44.3 | 800 | 28.22 | 82% |
| GWS HD 10x6 | 2.286 | 10.7 | 16.2 | 173 | 8400 | 47.7 | 944 | 33.30 | 80% |
| GWS HD 11x7 | 2.286 | 6.8 | 11.8 | 80 | 5280 | 35.0 | 604 | 21.31 | 80% |
| GWS HD 11x7 | 2.286 | 7.7 | 14.4 | 110 | 5850 | 38.8 | 750 | 26.46 | 78% |
| GWS HD 11x7 | 2.286 | 8.7 | 17 | 147 | 6360 | 42.2 | 900 | 31.75 | 75% |
| GWS HD 11x7 | 2.286 | 9.7 | 19.7 | 191 | 6840 | 45.3 | 1040 | 36.68 | 72% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 11x7 | 2.286 | 10.6 | 22.2 | 235 | 7290 | 48.3 | 1160 | 40.92 | 71% |
