NTM - 2830-750



Specifications

  • Type: Outrunner
  • Weight: 69.00g (2.43oz)
  • Diameter: 28.10mm (1.11in)
  • Length: 32.00mm (1.26in)
  • Shaft Diameter: 3.00mm (0.12in)
  • Maximum Amps: 12

Constants

  • kV: 730
  • Rm: 0.345
  • Io: 0.45



Io Test Data

Dr Kiwi test results
Volts Amps RPM
7 0.35 5045
8 0.4 5770
10 0.45 7170

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 9x5 1 6.9 2.35 16 4590 21.7 195 6.88 91%
GWS HD 9x5 1 7.9 2.9 22 5130 24.3 250 8.82 89%
GWS HD 9x5 1 8.9 3.4 30 5670 26.8 307 10.83 87%
GWS HD 9x5 1 9.9 4 39 6210 29.4 362 12.77 86%
GWS HD 9x5 1 10.9 4.65 50 6750 32.0 436 15.38 85%
GWS HD 3T 9x5 1 6.9 2.8 19 448 21.2 212 7.48 9%
GWS HD 3T 9x5 1 7.9 3.4 26 5020 23.8 272 9.59 87%
GWS HD 3T 9x5 1 8.9 4.1 36 5520 26.1 334 11.78 85%
GWS HD 3T 9x5 1 9.9 4.85 48 6040 28.6 408 14.39 84%
GWS HD 3T 9x5 1 10.8 5.55 59 6500 30.8 472 16.65 82%
GWS HD 3T 9x5 1 14 8 112 7960 37.7 713 25.15 78%
GWS HD 10x6 1 6.9 3.25 22 4350 24.7 257 9.07 86%
GWS HD 10x6 1 7.9 3.95 31 4860 27.6 326 11.50 84%
GWS HD 10x6 1 8.9 4.7 41 5370 30.5 398 14.04 83%
GWS HD 10x6 1 9.8 5.5 53 5850 33.2 470 16.58 82%
GWS HD 10x6 1 10.8 6.3 68 6300 35.8 546 19.26 80%
GWS HD 10x6 1 14 8.9 124 7740 44.0 794 28.01 76%
GWS HD 3T 10x6 1 6.9 4 27 4180 23.8 292 10.30 83%
GWS HD 3T 10x6 1 7.8 4.85 37 4680 26.6 364 12.84 82%
GWS HD 3T 10x6 1 8.8 5.7 50 5120 29.1 438 15.45 80%
GWS HD 3T 10x6 1 9.8 6.55 64 5540 31.5 516 18.20 77%
GWS HD 3T 10x6 1 10.7 7.5 80 5960 33.9 602 21.23 76%
GWS HD 3T 10x6 1 14 10.8 151 7200 40.9 909 32.06 70%
GWS HD 11x7 1 6.9 4.6 31 4080 27.0 356 12.56 81%
GWS HD 11x7 1 7.9 5.6 44 4500 29.8 436 15.38 78%
GWS HD 11x7 1 8.8 6.6 58 4920 32.6 522 18.41 77%
GWS HD 11x7 1 9.8 7.6 74 5340 35.4 612 21.59 75%
GWS HD 11x7 1 10.8 8.6 92 5700 37.8 706 24.90 72%
GWS HD 12x6 1 6.9 5.1 35 3930 22.3 387 13.65 78%
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 12x6 1 7.9 6.2 48 4350 24.7 488 17.21 75%
GWS HD 12x6 1 8.8 7.2 63 4740 26.9 580 20.46 74%
GWS HD 12x6 1 9.8 8.4 82 5130 29.1 682 24.06 72%
GWS HD 12x6 1 10.8 9.5 102 5460 31.0 770 27.16 69%
GWS HD 12x8 1 6.8 6.1 41 3690 28.0 421 14.85 74%
GWS HD 12x8 1 7.8 7.4 57 4050 30.7 512 18.06 71%
GWS HD 12x8 1 8.8 8.6 75 4380 33.2 615 21.69 68%
GWS HD 12x8 1 9.8 9.9 97 4740 35.9 706 24.90 66%
GWS HD 12x8 1 10.7 11.1 118 4980 37.7 783 27.62 64%
APC E 13x6.5 1 6.8 6.15 41 3690 22.7 450 15.87 74%
APC E 13x6.5 1 7.8 7.4 57 4050 24.9 552 19.47 71%
APC E 13x6.5 1 8.8 8.65 76 4380 27.0 654 23.07 68%
APC E 13x6.5 1 9.8 10 98 4740 29.2 760 26.81 66%
APC E 13x6.5 1 10.8 11.2 120 4980 30.7 850 29.98 63%
APC E 14x8.5 1 6.8 8.7 59 3150 25.4 470 16.58 63%
APC E 14x8.5 1 7.8 10.3 80 3420 27.5 570 20.11 60%
APC E 14x8.5 1 8.7 11.6 100 3690 29.7 670 23.63 58%
APC E 14x8.5 1 9.7 12.9 125 3930 31.6 775 27.34 56%
APC E 14x8.5 1 10.7 14.1 150 4110 33.1 875 30.86 53%

Comments

dodgemanx on 2011-06-10 21:58:22
Couple of comments, the motor is listed as an outrunner on HK's website, not an inrunner as listed here and could someone please post some 4s data.
