E-power - GC GT2203-1560
Specifications
- Type: Outrunner
- Weight: 20.00g (0.71oz)
- Diameter: 27.60mm (1.09in)
- Length: 19.50mm (0.77in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 6
Constants
- kV: 1805
- Rm: 0.781
- Io: 0.6
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.6 | 11760 |
| 8 | 0.6 | 13450 |
| 10 | 0.6 | 16730 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 6x3 | 1 | 7 | 2.6 | 18 | 9290 | 26.4 | 129 | 4.55 | 74% |
| GWS HD 6x3 | 1 | 7.4 | 2.7 | 19 | 9660 | 27.4 | 142 | 5.01 | 72% |
| GWS HD 6x3 | 1 | 7.9 | 2.9 | 22 | 10160 | 28.9 | 161 | 5.68 | 71% |
| GWS HD 6x3 | 1 | 8.9 | 3.35 | 29 | 11070 | 31.4 | 191 | 6.74 | 69% |
| GWS HD 6x3 | 1 | 9.9 | 3.85 | 38 | 11940 | 33.9 | 226 | 7.97 | 67% |
| GWS HD 6x3 | 1 | 10.9 | 4.35 | 47 | 12810 | 36.4 | 263 | 9.28 | 65% |
| GWS HD 7x3.5 | 1 | 7 | 3.2 | 22 | 8490 | 28.1 | 164 | 5.78 | 67% |
| GWS HD 7x3.5 | 1 | 7.4 | 3.4 | 25 | 8850 | 29.3 | 178 | 6.28 | 66% |
| GWS HD 7x3.5 | 1 | 7.9 | 3.65 | 28 | 9240 | 30.6 | 196 | 6.91 | 65% |
| GWS HD 7x3.5 | 1 | 8.9 | 4.3 | 38 | 10050 | 33.3 | 236 | 8.32 | 63% |
| GWS HD 7x3.5 | 1 | 9.8 | 4.85 | 47 | 10680 | 35.4 | 271 | 9.56 | 60% |
| GWS HD 7x3.5 | 1 | 10.8 | 5.5 | 59 | 11310 | 37.5 | 307 | 10.83 | 58% |
| GWS RS 8x4.3 | 1 | 7 | 5.8 | 40 | 5850 | 23.8 | 230 | 8.11 | 46% |
| GWS RS 8x4.3 | 1 | 7.4 | 6.1 | 45 | 5940 | 24.2 | 242 | 8.54 | 44% |
