TurBORIX - 4023-850
Specifications
- Type: Outrunner
- Weight: 107.00g (3.77oz)
- Shaft Diameter: 4.00mm (0.16in)
- Maximum Amps: 35
Constants
- kV: 893
- Rm: 0.105
- Io: 1.3
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.1 | 6150 |
| 8 | 1.15 | 7030 |
| 10 | 1.3 | 8770 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 10x5 | 1 | 6.8 | 6.7 | 45 | 5550 | 26.3 | 409 | 14.43 | 91% |
| APC E 10x5 | 1 | 7.8 | 8.2 | 63 | 6240 | 29.5 | 525 | 18.52 | 90% |
| APC E 10x5 | 1 | 8.8 | 9.9 | 87 | 6900 | 32.7 | 644 | 22.72 | 88% |
| APC E 10x5 | 1 | 9.7 | 11.7 | 113 | 7560 | 35.8 | 784 | 27.65 | 87% |
| APC E 10x5 | 1 | 10.7 | 13.6 | 145 | 8190 | 38.8 | 920 | 32.45 | 86% |
| APC E 10x5 | 1 | 13.1 | 18.4 | 241 | 9450 | 44.7 | 1270 | 44.80 | 81% |
| APC E 11x5.5 | 1 | 6.8 | 8.5 | 57 | 5400 | 28.1 | 527 | 18.59 | 89% |
| APC E 11x5.5 | 1 | 7.7 | 10.55 | 81 | 6030 | 31.4 | 663 | 23.39 | 88% |
| APC E 11x5.5 | 1 | 8.7 | 12.7 | 110 | 6630 | 34.5 | 818 | 28.85 | 85% |
| APC E 11x5.5 | 1 | 9.6 | 15.15 | 145 | 7200 | 37.5 | 976 | 34.43 | 84% |
| APC E 11x5.5 | 1 | 10.6 | 17.55 | 186 | 7800 | 40.6 | 1148 | 40.49 | 82% |
| APC E 11x7 | 1 | 6.8 | 10.8 | 73 | 5160 | 34.2 | 549 | 19.37 | 85% |
| APC E 11x7 | 1 | 7.7 | 13.4 | 103 | 5760 | 38.2 | 689 | 24.30 | 84% |
| APC E 11x7 | 1 | 8.6 | 15.4 | 132 | 6360 | 42.2 | 870 | 30.69 | 83% |
| APC E 11x7 | 1 | 9.6 | 18.25 | 175 | 6870 | 45.5 | 1040 | 36.68 | 80% |
| APC E 11x7 | 1 | 10.6 | 21 | 222 | 7410 | 49.1 | 1215 | 42.86 | 78% |
| APC E 11x7 | 1 | 13.1 | 29.3 | 383 | 8580 | 56.9 | 1662 | 58.63 | 73% |
| APC E 12x6 | 1 | 7.1 | 11.8 | 83 | 5280 | 30.0 | 707 | 24.94 | 83% |
| APC E 12x6 | 1 | 11.5 | 25.6 | 294 | 7590 | 43.1 | 1555 | 54.85 | 74% |
| APC E 12x8 | 1 | 6.7 | 13.65 | 91 | 4890 | 37.0 | 712 | 25.12 | 82% |
| APC E 12x8 | 1 | 7.6 | 16.6 | 126 | 5430 | 41.1 | 888 | 31.32 | 80% |
| APC E 12x8 | 1 | 8.6 | 19.8 | 170 | 5940 | 45.0 | 1070 | 37.74 | 77% |
| APC E 12x8 | 1 | 11.2 | 29.4 | 329 | 7110 | 53.9 | 1580 | 55.73 | 71% |
| APC E 13x4 | 1 | 7 | 11.15 | 78 | 5280 | 20.0 | 712 | 25.12 | 84% |
| APC E 13x4 | 1 | 11.6 | 25 | 290 | 7840 | 29.7 | 1724 | 60.81 | 76% |
| APC E 13x8 | 1 | 6.8 | 16.7 | 113 | 4680 | 35.5 | 860 | 30.34 | 77% |
| APC E 13x8 | 1 | 11 | 34.1 | 375 | 6540 | 49.5 | 1765 | 62.26 | 67% |
