SunnySky - X2216-7
Specifications
- Type: Outrunner
- Weight: 72.00g (2.54oz)
- Diameter: 27.80mm (1.09in)
- Length: 34.20mm (1.35in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 25
Constants
- kV: 1390
- Rm: 0.125
- Io: 1.6
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.35 | 9480 |
| 8 | 1.45 | 10835 |
| 10 | 1.6 | 13500 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 6x5.5 | 1 | 6.8 | 5.45 | 37 | 8640 | 45.0 | 161 | 5.68 | 91% |
| APC E 6x5.5 | 1 | 7.8 | 6.5 | 50 | 9720 | 50.6 | 208 | 7.34 | 90% |
| APC E 6x5.5 | 1 | 8.7 | 7.55 | 65 | 10800 | 56.2 | 257 | 9.07 | 89% |
| APC E 6x5.5 | 1 | 9.7 | 8.8 | 85 | 11850 | 61.7 | 310 | 10.93 | 88% |
| APC E 6x5.5 | 1 | 10.6 | 10.1 | 107 | 12870 | 67.0 | 372 | 13.12 | 87% |
| APC E 6x5.5 | 1 | 14 | 14.6 | 204 | 16170 | 84.2 | 605 | 21.34 | 83% |
| APC E 7x5 | 1 | 6.8 | 7.25 | 49 | 8370 | 39.6 | 303 | 10.69 | 89% |
| APC E 7x5 | 1 | 7.7 | 8.9 | 68 | 9300 | 44.0 | 385 | 13.58 | 87% |
| APC E 7x5 | 1 | 8.7 | 10.6 | 92 | 10260 | 48.6 | 468 | 16.51 | 85% |
| APC E 7x5 | 1 | 9.7 | 12.45 | 120 | 11190 | 53.0 | 568 | 20.04 | 83% |
| APC E 7x5 | 1 | 10.6 | 14.4 | 152 | 12030 | 57.0 | 665 | 23.46 | 82% |
| APC E 7x5 | 1 | 14 | 22 | 308 | 14850 | 70.3 | 1046 | 36.90 | 76% |
| APC Sport 7x7 | 1 | 6.8 | 8.8 | 59 | 8100 | 53.7 | 258 | 9.10 | 86% |
| APC Sport 7x7 | 1 | 7.7 | 10.6 | 81 | 9030 | 59.9 | 328 | 11.57 | 84% |
| APC Sport 7x7 | 1 | 8.7 | 12.3 | 107 | 9930 | 65.8 | 395 | 13.93 | 82% |
| APC Sport 7x7 | 1 | 9.7 | 14.4 | 139 | 10800 | 71.6 | 476 | 16.79 | 80% |
| APC Sport 7x7 | 1 | 10.6 | 16.25 | 172 | 11640 | 77.2 | 556 | 19.61 | 79% |
| GWS HD 8x4 | 1 | 6.8 | 7 | 47 | 8400 | 31.8 | 359 | 12.66 | 89% |
| GWS HD 8x4 | 1 | 7.8 | 8.5 | 66 | 9390 | 35.6 | 458 | 16.16 | 87% |
| GWS HD 8x4 | 1 | 8.7 | 10.1 | 87 | 10320 | 39.1 | 560 | 19.75 | 85% |
| GWS HD 8x4 | 1 | 9.7 | 11.95 | 115 | 11280 | 42.7 | 670 | 23.63 | 84% |
| GWS HD 8x4 | 1 | 10.6 | 13.85 | 146 | 12120 | 45.9 | 782 | 27.58 | 82% |
| GWS HD 9x5 | 1 | 6.7 | 11.45 | 76 | 7620 | 36.1 | 566 | 19.97 | 82% |
| GWS HD 9x5 | 1 | 7.6 | 13.85 | 105 | 8430 | 39.9 | 690 | 24.34 | 80% |
| GWS HD 9x5 | 1 | 8.6 | 16.4 | 141 | 9240 | 43.8 | 830 | 29.28 | 77% |
| GWS HD 9x5 | 1 | 9.6 | 19.3 | 185 | 9960 | 47.2 | 995 | 35.10 | 75% |
| GWS HD 9x5 | 1 | 10.5 | 21.7 | 227 | 10620 | 50.3 | 1136 | 40.07 | 73% |
| GWS HD 10x6 | 1 | 7.4 | 17.25 | 127 | 7650 | 43.5 | 793 | 27.97 | 74% |
| GWS HD 10x6 | 1 | 11.1 | 29.5 | 327 | 10150 | 57.7 | 1400 | 49.38 | 66% |
