SunnySky - X2814-8
Specifications
- Type: Outrunner
- Weight: 110.00g (3.88oz)
- Diameter: 35.00mm (1.38in)
- Length: 34.30mm (1.35in)
- Shaft Diameter: 4.00mm (0.16in)
- Maximum Amps: 30
Constants
- kV: 1000
- Rm: 0.091
- Io: 1.7
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.45 | 6860 |
| 8 | 1.55 | 7830 |
| 10 | 1.7 | 9760 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 9x5 | 1 | 6.8 | 6.45 | 43 | 6270 | 29.7 | 373 | 13.16 | 92% |
| GWS HD 9x5 | 1 | 7.7 | 7.9 | 60 | 7020 | 33.2 | 476 | 16.79 | 91% |
| GWS HD 9x5 | 1 | 8.7 | 9.35 | 81 | 7740 | 36.6 | 580 | 20.46 | 89% |
| GWS HD 9x5 | 1 | 9.7 | 11.15 | 108 | 8550 | 40.5 | 710 | 25.04 | 88% |
| GWS HD 9x5 | 1 | 10.6 | 12.9 | 136 | 9240 | 43.8 | 840 | 29.63 | 87% |
| GWS HD 10x6 | 1 | 6.8 | 8.6 | 58 | 6030 | 34.3 | 487 | 17.18 | 89% |
| GWS HD 10x6 | 1 | 7.7 | 10.45 | 80 | 6750 | 38.4 | 602 | 21.23 | 88% |
| GWS HD 10x6 | 1 | 8.7 | 12.45 | 108 | 7470 | 42.4 | 735 | 25.93 | 86% |
| GWS HD 10x6 | 1 | 9.6 | 14.75 | 141 | 8130 | 46.2 | 880 | 31.04 | 85% |
| GWS HD 10x6 | 1 | 10.6 | 17 | 180 | 8790 | 49.9 | 1041 | 36.72 | 83% |
| GWS HD 11x7 | 1 | 6.6 | 12.65 | 83 | 5580 | 37.0 | 675 | 23.81 | 85% |
| GWS HD 11x7 | 1 | 7.6 | 15.5 | 117 | 6210 | 41.2 | 840 | 29.63 | 82% |
| GWS HD 11x7 | 1 | 8.6 | 18.3 | 157 | 6810 | 45.1 | 1004 | 35.42 | 79% |
| GWS HD 11x7 | 1 | 9.6 | 22.1 | 212 | 7500 | 49.7 | 1239 | 43.70 | 78% |
| GWS HD 11x7 | 1 | 10.6 | 25 | 265 | 8040 | 53.3 | 1419 | 50.05 | 76% |
| GWS HD 11x7 | 1 | 11.1 | 27.3 | 303 | 8280 | 54.9 | 1525 | 53.79 | 75% |
