Turnigy - SK3 3530-1340
Specifications
- Type: Outrunner
- Weight: 76.00g (2.68oz)
- Diameter: 37.20mm (1.46in)
- Length: 30.70mm (1.21in)
- Shaft Diameter: 4.00mm (0.16in)
- Maximum Amps: 30
Constants
- kV: 1380
- Rm: 0.09
- Io: 1.7
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.35 | 9500 |
| 8 | 1.5 | 10825 |
| 10 | 1.7 | 13520 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| EMP 6x5 | 1 | 6.9 | 4.5 | 31 | 8970 | 42.5 | 189 | 6.67 | 94% |
| EMP 6x5 | 1 | 7.9 | 5.5 | 43 | 10260 | 48.6 | 247 | 8.71 | 94% |
| EMP 6x5 | 1 | 8.9 | 6.7 | 59 | 11490 | 54.4 | 313 | 11.04 | 94% |
| EMP 6x5 | 1 | 9.9 | 7.8 | 77 | 12570 | 59.5 | 374 | 13.19 | 92% |
| EMP 6x5 | 1 | 10.9 | 9.15 | 99 | 13800 | 65.3 | 452 | 15.94 | 92% |
| EMP 6x5 | 1 | 14 | 14 | 196 | 17310 | 82.0 | 690 | 24.34 | 90% |
| GWS HD 8x4 | 1 | 6.8 | 7.7 | 52 | 8610 | 32.6 | 387 | 13.65 | 92% |
| GWS HD 8x4 | 1 | 7.8 | 9.5 | 74 | 9690 | 36.7 | 496 | 17.50 | 90% |
| GWS HD 8x4 | 1 | 8.8 | 11.65 | 102 | 10740 | 40.7 | 624 | 22.01 | 88% |
| GWS HD 8x4 | 1 | 9.7 | 13.75 | 133 | 11700 | 44.3 | 744 | 26.24 | 87% |
| GWS HD 8x4 | 1 | 10.7 | 16.1 | 172 | 12630 | 47.8 | 875 | 30.86 | 86% |
| GWS HD 9x5 | 1 | 6.7 | 12.8 | 85 | 7860 | 37.2 | 604 | 21.31 | 85% |
| GWS HD 9x5 | 1 | 7.6 | 15.85 | 120 | 8730 | 41.3 | 763 | 26.91 | 83% |
| GWS HD 9x5 | 1 | 8.6 | 19.1 | 164 | 9600 | 45.5 | 922 | 32.52 | 81% |
| GWS HD 9x5 | 1 | 9.5 | 22.5 | 213 | 10350 | 49.0 | 1079 | 38.06 | 79% |
| GWS HD 9x5 | 1 | 11.1 | 28 | 310 | 11460 | 54.3 | 1350 | 47.62 | 75% |
| GWS HD 9x5 | 1 | 11.4 | 29.5 | 336 | 11580 | 54.8 | 1400 | 49.38 | 74% |
