SunnySky - X2212-9
Specifications
- Type: Outrunner
- Weight: 58.00g (2.05oz)
- Diameter: 27.50mm (1.08in)
- Length: 30.00mm (1.18in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 20
Constants
- kV: 1300
- Rm: 0.136
- Io: 1.05
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.85 | 9000 |
| 8 | 0.95 | 10260 |
| 10 | 1.05 | 12800 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 7x3.5 | 1 | 6.9 | 3.1 | 21 | 8610 | 28.5 | 169 | 5.96 | 96% |
| GWS HD 7x3.5 | 1 | 7.8 | 3.8 | 29 | 9690 | 32.1 | 224 | 7.90 | 96% |
| GWS HD 7x3.5 | 1 | 8.8 | 4.6 | 40 | 10800 | 35.8 | 283 | 9.98 | 94% |
| GWS HD 7x3.5 | 1 | 9.8 | 5.4 | 52 | 11850 | 39.3 | 350 | 12.35 | 93% |
| GWS HD 7x3.5 | 1 | 10.8 | 6.2 | 66 | 12840 | 42.6 | 419 | 14.78 | 91% |
| APC Sport 7x7 | 1 | 6.8 | 7.6 | 51 | 7740 | 51.3 | 233 | 8.22 | 88% |
| APC Sport 7x7 | 1 | 7.7 | 9.1 | 70 | 8640 | 57.3 | 292 | 10.30 | 86% |
| APC Sport 7x7 | 1 | 8.7 | 10.7 | 93 | 9480 | 62.8 | 358 | 12.63 | 84% |
| APC Sport 7x7 | 1 | 9.7 | 12.4 | 120 | 10350 | 68.6 | 428 | 15.10 | 82% |
| APC Sport 7x7 | 1 | 10.7 | 14.2 | 151 | 11250 | 74.6 | 507 | 17.88 | 81% |
| APC Sport 7x7 | 1 | 14 | 20.2 | 282 | 13860 | 91.9 | 794 | 28.01 | 76% |
| GWS HD 8x4 | 1 | 6.8 | 5.9 | 40 | 8040 | 30.5 | 327 | 11.53 | 91% |
| GWS HD 8x4 | 1 | 7.8 | 7.15 | 55 | 8970 | 34.0 | 411 | 14.50 | 88% |
| GWS HD 8x4 | 1 | 8.7 | 8.7 | 75 | 9900 | 37.5 | 513 | 18.10 | 88% |
| GWS HD 8x4 | 1 | 9.7 | 10.25 | 99 | 10800 | 40.9 | 620 | 21.87 | 86% |
| GWS HD 8x4 | 1 | 10.6 | 11.95 | 126 | 11610 | 44.0 | 712 | 25.12 | 84% |
| GWS HD 8x6 | 1 | 6.7 | 9.2 | 61 | 7380 | 41.9 | 381 | 13.44 | 85% |
| GWS HD 8x6 | 1 | 7.7 | 11.4 | 87 | 8160 | 46.4 | 473 | 16.68 | 82% |
| GWS HD 8x6 | 1 | 8.6 | 13.5 | 116 | 8940 | 50.8 | 565 | 19.93 | 80% |
| GWS HD 8x6 | 1 | 9.6 | 15.6 | 149 | 9690 | 55.1 | 668 | 23.56 | 78% |
| GWS HD 8x6 | 1 | 10.6 | 18 | 190 | 10320 | 58.6 | 755 | 26.63 | 75% |
| GWS HD 9x5 | 1 | 6.7 | 9.8 | 65 | 7290 | 34.5 | 511 | 18.02 | 84% |
| GWS HD 9x5 | 1 | 7.7 | 12.2 | 93 | 8160 | 38.6 | 652 | 23.00 | 82% |
| GWS HD 9x5 | 1 | 8.6 | 14.05 | 120 | 8790 | 41.6 | 745 | 26.28 | 79% |
| GWS HD 9x5 | 1 | 9.6 | 16.4 | 157 | 9450 | 44.7 | 880 | 31.04 | 76% |
| GWS HD 9x5 | 1 | 10.6 | 18.9 | 200 | 10140 | 48.0 | 1015 | 35.80 | 74% |
