AX - AX-1406N 2000
Specifications
- Type: Outrunner
- Weight: 11.00g (0.39oz)
- Diameter: 17.00mm (0.67in)
- Length: 20.00mm (0.79in)
- Shaft Diameter: 1.50mm (0.06in)
- Maximum Amps: 3
Constants
- kV: 2097
- Rm: 0.95
- Io: 0.22
Io Test Data
Bruce Abbot test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.22 | 14229 |
Test Data
Bruce Abbot test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS EP 4x2.5 | 1 | 7 | 1.37 | 9 | 11788 | 27.9 | 61 | 2.15 | 80% |
| GWS HD 4.5x3 | 1 | 7 | 1.68 | 11 | 11086 | 31.5 | 79 | 2.79 | 76% |
| GWS EP 5x3 | 1 | 7 | 1.91 | 13 | 10607 | 30.1 | 100 | 3.53 | 72% |
| GWS EP 5x4.3 | 1 | 7 | 2.58 | 18 | 9380 | 38.2 | 106 | 3.74 | 64% |
| GWS EP 6x3 | 1 | 7 | 2.61 | 18 | 9126 | 25.9 | 125 | 4.41 | 62% |
