Dualsky - XM2830EA-11
Specifications
- Type: Outrunner
- Weight: 56.00g (1.98oz)
- Diameter: 27.60mm (1.09in)
- Length: 27.80mm (1.09in)
- Shaft Diameter: 3.12mm (0.12in)
- Maximum Amps: 15
Constants
- kV: 1020
- Rm: 0.195
- Io: 1.05
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.9 | 6950 |
| 8 | 1 | 7950 |
| 10 | 1.05 | 9910 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 7x3.5 | 1 | 7 | 2 | 14 | 6750 | 22.4 | 98 | 3.46 | 95% |
| GWS HD 7x3.5 | 1 | 7.9 | 2.3 | 18 | 7620 | 25.3 | 125 | 4.41 | 95% |
| GWS HD 7x3.5 | 1 | 8.9 | 2.7 | 24 | 8520 | 28.2 | 161 | 5.68 | 94% |
| GWS HD 7x3.5 | 1 | 9.9 | 3.1 | 30 | 9450 | 31.3 | 205 | 7.23 | 94% |
| GWS HD 7x3.5 | 1 | 10.9 | 3.55 | 38 | 10350 | 34.3 | 250 | 8.82 | 93% |
| GWS HD 8x4 | 1 | 6.9 | 3.5 | 24 | 6390 | 24.2 | 218 | 7.69 | 91% |
| GWS HD 8x4 | 1 | 7.9 | 4.3 | 33 | 7260 | 27.5 | 287 | 10.12 | 90% |
| GWS HD 8x4 | 1 | 8.8 | 5.05 | 44 | 8010 | 30.3 | 347 | 12.24 | 89% |
| GWS HD 8x4 | 1 | 9.8 | 5.95 | 58 | 8820 | 33.4 | 420 | 14.82 | 88% |
| GWS HD 8x4 | 1 | 10.8 | 6.9 | 74 | 9570 | 36.2 | 503 | 17.74 | 87% |
| GWS HD 9x5 | 1 | 6.8 | 5.6 | 38 | 6000 | 28.4 | 347 | 12.24 | 87% |
| GWS HD 9x5 | 1 | 7.8 | 6.85 | 53 | 6690 | 31.7 | 435 | 15.34 | 84% |
| GWS HD 9x5 | 1 | 8.8 | 8.1 | 71 | 7380 | 34.9 | 530 | 18.70 | 82% |
| GWS HD 9x5 | 1 | 9.8 | 9.65 | 94 | 8070 | 38.2 | 630 | 22.22 | 81% |
| GWS HD 9x5 | 1 | 10.7 | 11.05 | 118 | 8700 | 41.2 | 735 | 25.93 | 80% |
| GWS HD 10x6 | 1 | 6.8 | 7.4 | 50 | 5640 | 32.0 | 434 | 15.31 | 81% |
| GWS HD 10x6 | 1 | 7.8 | 9.15 | 71 | 6300 | 35.8 | 545 | 19.22 | 79% |
| GWS HD 10x6 | 1 | 8.7 | 10.65 | 92 | 6900 | 39.2 | 642 | 22.65 | 78% |
| GWS HD 10x6 | 1 | 9.7 | 12.4 | 120 | 7470 | 42.4 | 767 | 27.06 | 76% |
| GWS HD 10x6 | 1 | 10.7 | 14.2 | 151 | 7980 | 45.3 | 885 | 31.22 | 73% |
| XOAR 10x6 | 1 | 6.8 | 9.1 | 61 | 5310 | 30.2 | 386 | 13.62 | 77% |
| XOAR 10x6 | 1 | 7.7 | 10.95 | 84 | 5910 | 33.6 | 495 | 17.46 | 75% |
| XOAR 10x6 | 1 | 8.7 | 12.8 | 111 | 6480 | 36.8 | 604 | 21.31 | 73% |
| XOAR 10x6 | 1 | 9.7 | 14.7 | 142 | 6960 | 39.5 | 722 | 25.47 | 70% |
| XOAR 10x6 | 1 | 10.6 | 16.6 | 175 | 7380 | 41.9 | 827 | 29.17 | 68% |
| GWS HD 11x7 | 1 | 6.7 | 10.45 | 70 | 5040 | 33.4 | 565 | 19.93 | 74% |
| GWS HD 11x7 | 1 | 7.7 | 12.55 | 96 | 5580 | 37.0 | 689 | 24.30 | 71% |
| GWS HD 11x7 | 1 | 8.6 | 14.7 | 126 | 6030 | 40.0 | 790 | 27.87 | 69% |
| GWS HD 11x7 | 1 | 9.6 | 16.65 | 159 | 6450 | 42.8 | 904 | 31.89 | 66% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 11x7 | 1 | 10.6 | 18.6 | 197 | 6780 | 44.9 | 1020 | 35.98 | 63% |
