Exceed - Rocket 3010-1820
Specifications
- Type: Outrunner
- Weight: 91.00g (3.21oz)
- Diameter: 37.00mm (1.46in)
- Length: 36.00mm (1.42in)
- Shaft Diameter: 4.00mm (0.16in)
- Maximum Amps: 35
Constants
- kV: 1820
- Rm: 0.064
- Io: 1.8
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 1.4 | 12530 |
| 8 | 1.55 | 14560 |
| 10 | 1.8 | 17930 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| EMP 6x5 | 1 | 6.8 | 7.8 | 53 | 11310 | 53.6 | 299 | 10.55 | 91% |
| EMP 6x5 | 1 | 7.8 | 9.75 | 76 | 12780 | 60.5 | 389 | 13.72 | 90% |
| EMP 6x5 | 1 | 8.8 | 11.8 | 103 | 14220 | 67.3 | 475 | 16.76 | 89% |
| EMP 6x5 | 1 | 9.7 | 14.3 | 138 | 15660 | 74.1 | 578 | 20.39 | 89% |
| EMP 6x5 | 1 | 10.7 | 16.55 | 177 | 16860 | 79.8 | 678 | 23.92 | 87% |
| APC E 6x5.5 | 1 | 6.8 | 10 | 68 | 11070 | 57.7 | 254 | 8.96 | 89% |
| APC E 6x5.5 | 1 | 7.8 | 12.3 | 95 | 12300 | 64.1 | 327 | 11.53 | 87% |
| APC E 6x5.5 | 1 | 8.7 | 14.7 | 127 | 13770 | 71.7 | 402 | 14.18 | 87% |
| APC E 6x5.5 | 1 | 9.7 | 17.3 | 167 | 15180 | 79.1 | 490 | 17.28 | 86% |
| APC E 6x5.5 | 1 | 10.6 | 20 | 212 | 16410 | 85.5 | 580 | 20.46 | 85% |
| APC E 7x5 | 1 | 7.7 | 17.35 | 133 | 11670 | 55.3 | 596 | 21.02 | 83% |
| APC E 7x5 | 1 | 11.1 | 32.6 | 361 | 15390 | 72.9 | 1038 | 36.61 | 76% |
| APC E 8x4 | 1 | 7.8 | 21.7 | 169 | 11100 | 42.0 | 800 | 28.22 | 78% |
| APC E 8x4 | 1 | 10.8 | 38.6 | 416 | 14250 | 54.0 | 1400 | 49.38 | 72% |
| APC E 8x6 | 1 | 7.7 | 30.7 | 236 | 9900 | 56.2 | 750 | 26.46 | 71% |
