LittleScreamers - Purple Peril (production)
Specifications
- Type: Outrunner
- Weight: 25.00g (0.88oz)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 16
Constants
- kV: 1810
- Rm: 0.335
- Io: 0.54
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7.03 | 0.39 | 12540 |
| 8.03 | 0.45 | 14340 |
| 10.04 | 0.54 | 17820 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| APC E 4.75x4.75 | 1 | 6.9 | 3.5 | 24 | 10560 | 47.5 | 102 | 3.60 | 85% |
| APC E 4.75x4.75 | 1 | 7.9 | 4.2 | 33 | 11850 | 53.3 | 127 | 4.48 | 83% |
| APC E 4.75x4.75 | 1 | 8.9 | 5 | 44 | 13050 | 58.7 | 157 | 5.54 | 81% |
| APC E 4.75x4.75 | 1 | 9.9 | 5.85 | 57 | 14220 | 64.0 | 187 | 6.60 | 79% |
| APC E 4.75x4.75 | 1 | 10.9 | 6.7 | 73 | 15240 | 68.5 | 218 | 7.69 | 77% |
| Zagi Carbon 5.1x4.9 | 1 | 6.9 | 3.75 | 25 | 10500 | 48.7 | 152 | 5.36 | 84% |
| Zagi Carbon 5.1x4.9 | 1 | 7.9 | 4.5 | 35 | 11700 | 54.3 | 190 | 6.70 | 82% |
| Zagi Carbon 5.1x4.9 | 1 | 8.9 | 5.3 | 47 | 12840 | 59.6 | 226 | 7.97 | 80% |
| Zagi Carbon 5.1x4.9 | 1 | 9.9 | 6.2 | 61 | 14040 | 65.2 | 268 | 9.45 | 78% |
| Zagi Carbon 5.1x4.9 | 1 | 10.9 | 7.2 | 78 | 15090 | 70.0 | 312 | 11.01 | 76% |
| Zagi Carbon 5.1x4.9 | 1 | 14 | 10.7 | 149 | 17970 | 83.4 | 458 | 16.16 | 71% |
| Zagi Carbon 5.1x4.9 | 1 | 14.6 | 11.6 | 169 | 18480 | 85.8 | 492 | 17.35 | 70% |
| APC E 5.25x6.25 | 1 | 6.9 | 5.35 | 36 | 9660 | 57.2 | 128 | 4.52 | 77% |
| APC E 5.25x6.25 | 1 | 7.9 | 6.45 | 50 | 10590 | 62.7 | 160 | 5.64 | 74% |
| APC E 5.25x6.25 | 1 | 8.9 | 7.65 | 68 | 11580 | 68.5 | 190 | 6.70 | 72% |
| APC E 5.25x6.25 | 1 | 9.9 | 8.8 | 87 | 12450 | 73.7 | 221 | 7.80 | 69% |
| APC E 5.25x6.25 | 1 | 10.9 | 10.25 | 111 | 13260 | 78.5 | 254 | 8.96 | 67% |
| APC E 5.5x4.5 | 1 | 6.9 | 4.4 | 30 | 10110 | 43.1 | 147 | 5.19 | 81% |
| APC E 5.5x4.5 | 1 | 7.9 | 5.45 | 43 | 11220 | 47.8 | 186 | 6.56 | 78% |
| APC E 5.5x4.5 | 1 | 8.9 | 6.4 | 56 | 12180 | 51.9 | 222 | 7.83 | 76% |
| APC E 5.5x4.5 | 1 | 9.9 | 7.6 | 75 | 13230 | 56.4 | 266 | 9.38 | 74% |
| APC E 5.5x4.5 | 1 | 10.9 | 8.7 | 94 | 14220 | 60.6 | 308 | 10.86 | 72% |
| Windsor 6x3 | 1 | 6.9 | 4.3 | 29 | 10200 | 29.0 | 183 | 6.46 | 82% |
| Windsor 6x3 | 1 | 7.9 | 5.15 | 40 | 11310 | 32.1 | 237 | 8.36 | 79% |
| Windsor 6x3 | 1 | 8.9 | 6.1 | 54 | 12420 | 35.3 | 289 | 10.19 | 77% |
| Windsor 6x3 | 1 | 9.9 | 7.1 | 70 | 13410 | 38.1 | 340 | 11.99 | 75% |
| Windsor 6x3 | 1 | 10.9 | 8.2 | 89 | 14400 | 40.9 | 405 | 14.29 | 73% |
| MAS 6x3 | 1 | 6.9 | 5.5 | 37 | 9540 | 27.1 | 147 | 5.19 | 76% |
| MAS 6x3 | 1 | 7.9 | 6.6 | 52 | 10500 | 29.8 | 179 | 6.31 | 73% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| MAS 6x3 | 1 | 8.9 | 7.8 | 69 | 11430 | 32.5 | 217 | 7.65 | 71% |
| MAS 6x3 | 1 | 9.9 | 9.1 | 90 | 12300 | 34.9 | 254 | 8.96 | 69% |
| MAS 6x3 | 1 | 10.9 | 10.4 | 113 | 13110 | 37.2 | 290 | 10.23 | 66% |
| Cox 6x3 | 1 | 7 | 3.95 | 27 | 10440 | 29.7 | 193 | 6.81 | 82% |
| Cox 6x3 | 1 | 7.9 | 4.8 | 37 | 11550 | 32.8 | 244 | 8.61 | 81% |
| Cox 6x3 | 1 | 8.9 | 5.7 | 50 | 12600 | 35.8 | 297 | 10.48 | 78% |
| Cox 6x3 | 1 | 9.9 | 6.7 | 66 | 13680 | 38.9 | 353 | 12.45 | 76% |
| Cox 6x3 | 1 | 10.9 | 7.8 | 85 | 14640 | 41.6 | 422 | 14.89 | 74% |
| APC E 6x4 | 1 | 6.9 | 4.6 | 31 | 10020 | 38.0 | 195 | 6.88 | 80% |
| APC E 6x4 | 1 | 7.9 | 5.55 | 43 | 11130 | 42.2 | 245 | 8.64 | 78% |
| APC E 6x4 | 1 | 8.9 | 6.55 | 58 | 12150 | 46.0 | 296 | 10.44 | 75% |
| APC E 6x4 | 1 | 9.9 | 7.7 | 76 | 13140 | 49.8 | 350 | 12.35 | 73% |
| APC E 6x4 | 1 | 10.9 | 8.8 | 95 | 14070 | 53.3 | 404 | 14.25 | 71% |
| MAS 3-blade 6x4 | 1 | 6.9 | 5.8 | 40 | 9400 | 35.6 | 177 | 6.24 | 75% |
| MAS 3-blade 6x4 | 1 | 7.9 | 7 | 55 | 10340 | 39.2 | 221 | 7.80 | 72% |
| MAS 3-blade 6x4 | 1 | 8.9 | 8.1 | 72 | 11240 | 42.6 | 264 | 9.31 | 70% |
| MAS 3-blade 6x4 | 1 | 9.9 | 9.5 | 94 | 12100 | 45.8 | 315 | 11.11 | 68% |
| MAS 3-blade 6x4 | 1 | 10.9 | 10.7 | 116 | 12800 | 48.5 | 357 | 12.59 | 65% |
| APC E 6x5.5 | 1 | 6.9 | 6.2 | 42 | 9180 | 47.8 | 186 | 6.56 | 74% |
| APC E 6x5.5 | 1 | 7.9 | 7.35 | 58 | 10080 | 52.5 | 229 | 8.08 | 70% |
| APC E 6x5.5 | 1 | 8.9 | 8.65 | 76 | 10950 | 57.0 | 272 | 9.59 | 68% |
| APC E 6x5.5 | 1 | 9.9 | 9.85 | 97 | 11730 | 61.1 | 318 | 11.22 | 65% |
| APC E 6x5.5 | 1 | 10.9 | 11.3 | 123 | 12540 | 65.3 | 368 | 12.98 | 64% |
| Aeronaut 6.5x4 | 1 | 6.9 | 5.55 | 38 | 9450 | 35.8 | 243 | 8.57 | 76% |
| Aeronaut 6.5x4 | 1 | 7.9 | 6.65 | 52 | 10500 | 39.8 | 302 | 10.65 | 73% |
| Aeronaut 6.5x4 | 1 | 8.9 | 7.85 | 69 | 11460 | 43.4 | 360 | 12.70 | 71% |
| Aeronaut 6.5x4 | 1 | 9.9 | 9 | 89 | 12300 | 46.6 | 429 | 15.13 | 69% |
| Aeronaut 6.5x4 | 1 | 10.9 | 10.2 | 111 | 13050 | 49.4 | 486 | 17.14 | 66% |
| GWS HD 7x3.5 | 1 | 6.9 | 4.7 | 32 | 10050 | 33.3 | 249 | 8.78 | 80% |
| GWS HD 7x3.5 | 1 | 7.9 | 5.65 | 44 | 11070 | 36.7 | 308 | 10.86 | 77% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 7x3.5 | 1 | 8.9 | 6.7 | 59 | 12120 | 40.2 | 377 | 13.30 | 75% |
| GWS HD 7x3.5 | 1 | 9.9 | 7.8 | 77 | 13110 | 43.5 | 442 | 15.59 | 73% |
| GWS HD 7x3.5 | 1 | 10.9 | 9.05 | 98 | 13950 | 46.2 | 515 | 18.17 | 71% |
| MAS 3-blade 7x4 | 1 | 6.9 | 8 | 55 | 8320 | 31.5 | 254 | 8.96 | 67% |
| MAS 3-blade 7x4 | 1 | 7.9 | 9.4 | 74 | 9000 | 34.1 | 315 | 11.11 | 63% |
| MAS 3-blade 7x4 | 1 | 8.9 | 10.8 | 96 | 9640 | 36.5 | 365 | 12.87 | 60% |
| MAS 3-blade 7x4 | 1 | 9.9 | 12.5 | 123 | 10200 | 38.6 | 430 | 15.17 | 57% |
| MAS 3-blade 7x4 | 1 | 10.9 | 14.1 | 153 | 10640 | 40.3 | 482 | 17.00 | 54% |
| APC E 7x5 | 1 | 6.9 | 8.1 | 55 | 8280 | 39.2 | 317 | 11.18 | 66% |
| APC E 7x5 | 1 | 7.9 | 9.55 | 75 | 8970 | 42.5 | 376 | 13.26 | 63% |
| APC E 7x5 | 1 | 8.9 | 11.1 | 98 | 9660 | 45.7 | 438 | 15.45 | 60% |
| APC E 7x5 | 1 | 9.9 | 13 | 128 | 10200 | 48.3 | 500 | 17.64 | 57% |
| APC E 7x5 | 1 | 10.9 | 14.5 | 158 | 10620 | 50.3 | 540 | 19.05 | 54% |
| GWS HD 8x4 | 1 | 6.9 | 8 | 55 | 8310 | 31.5 | 373 | 13.16 | 67% |
| GWS HD 8x4 | 1 | 7.9 | 9.5 | 75 | 9000 | 34.1 | 442 | 15.59 | 63% |
| GWS HD 8x4 | 1 | 8.9 | 11.3 | 100 | 9600 | 36.4 | 518 | 18.27 | 60% |
| GWS HD 8x4 | 1 | 9.9 | 13 | 128 | 10110 | 38.3 | 578 | 20.39 | 56% |
| GWS HD 8x4 | 1 | 10.9 | 14 | 152 | 10560 | 40.0 | 626 | 22.08 | 54% |
| GWS HD 9x5 | 1 | 6.8 | 11.4 | 77 | 6510 | 30.8 | 439 | 15.49 | 53% |
