LightFlightRC - 28-37-2 Black



Specifications

  • Type: Inrunner
  • Weight: 83.00g (2.93oz)
  • Diameter: 28.00mm (1.10in)
  • Length: 37.15mm (1.46in)
  • Shaft Diameter: 3.17mm (0.12in)
  • Maximum Amps: 30

Constants

  • kV: 3920
  • Rm: 0.07
  • Io: 2.51



Io Test Data

Dr Kiwi test results
Volts Amps RPM
10 2.51 38760

Test Data

Dr Kiwi test results
Propeller Gear Ratio Volts Amps Watts RPM Speed (mph) Thrust (g) Thrust (oz) RPM as % of Kv*V
GWS HD 8x4 3.167 6.9 7.5 51 7980 30.2 338 11.92 93%
GWS HD 8x4 3.167 7.9 9 71 9030 34.2 436 15.38 92%
GWS HD 8x4 3.167 8.9 11.1 98 10110 38.3 555 19.58 92%
GWS HD 8x4 3.167 9.9 13.25 131 11070 41.9 670 23.63 90%
GWS HD 8x4 3.167 10.9 15.7 171 12120 45.9 810 28.57 90%
APC E 8x4 3.167 6.9 9.5 65 7860 29.8 397 14.00 92%
APC E 8x4 3.167 7.9 11.2 88 8940 33.9 520 18.34 91%
APC E 8x4 3.167 8.9 13.7 121 9900 37.5 648 22.86 90%
APC E 8x4 3.167 9.9 16.85 166 10860 41.1 790 27.87 89%
APC E 8x4 3.167 10.9 19.7 214 11760 44.5 929 32.77 87%
APC E 8x8 3.167 7.6 19.7 149 7860 59.5 544 19.19 84%
APC E 8x8 3.167 10.9 35 381 10350 78.4 959 33.83 77%
GWS HD 9x5 3.167 7.7 15.7 120 8370 39.6 725 25.57 88%
GWS HD 10x6 3.167 7.6 20.2 153 7770 44.1 870 30.69 83%
GWS HD 10x6 3.167 10.9 36.9 402 10200 58.0 1530 53.97 76%
